Analog Output Expansion Solution – LENZE EPM-S501.2A.10 | EPM Series
Where This Product Is Used
The LENZE EPM-S501.2A.10 is an analog output expansion module designed for integration with LENZE ECS/EPM series servo drives and motion controllers. It is widely deployed in high-precision industrial environments where analog setpoint signals must be generated or monitored in real time. Typical deployment sites include:
- Packaging Machinery – Provides analog speed/torque references to downstream actuators and tension controllers in form-fill-seal and cartoning lines.
- CNC Machine Tools – Supplies analog command signals to spindle drives and auxiliary axes requiring ±10 V or 0–20 mA interfaces.
- Printing & Converting Equipment – Enables precise web tension and register control via analog output loops.
- Material Handling & Conveyors – Interfaces with variable-speed drives and proportional valves for smooth speed profiling.
- Robotics & Assembly Automation – Delivers analog reference signals to collaborative robot controllers and servo amplifiers.
- Textile & Wire Drawing Machines – Maintains constant tension through closed-loop analog feedback chains.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | EPM-S501.2A.10 |
| Manufacturer | LENZE |
| Series | ECS/EPM Drive Expansion |
| Module Type | Analog Output Expansion |
| Output Channels | 2 × Analog Outputs |
| Output Signal Range | ±10 V / 0–20 mA (configurable) |
| Resolution | 12-bit (typical for EPM series) |
| Compatible Drives | LENZE ECS / EPM Series |
| Mounting | Direct plug-in to ECS/EPM drive slot |
| Weight | 150 g |
| SKU | EPM-S501.2A.10 |
Note: Confirm exact electrical ratings against the LENZE EPM-S501 datasheet before commissioning.
Why Engineers Specify This Model
- Native Drive Integration – Plugs directly into the ECS/EPM expansion slot; no external signal conditioning required.
- Dual-Channel Output – Two independent analog outputs allow simultaneous control of multiple downstream devices from a single module.
- High Resolution – 12-bit DAC resolution ensures smooth, jitter-free analog references critical for precision motion profiles.
- Compact Form Factor – Slot-mounted design preserves panel space and simplifies cable routing.
- Proven LENZE Ecosystem – Fully supported by LENZE Engineer and Global Drive Control (GDC) software for rapid parameterization.
- Long Service Life – Industrial-grade components rated for continuous 24/7 operation in demanding factory environments.
Complete System Bill of Materials
For a fully functional analog output expansion system based on the EPM-S501.2A.10, engineers typically specify:
- LENZE ECS or EPM Series Servo Drive (base unit)
- EPM-S501.2A.10 – Analog Output Expansion Module (this item)
- LENZE EPM-S500 Communication Module (fieldbus interface, if required)
- Shielded analog signal cable (twisted-pair, ≤ 30 m recommended)
- 24 V DC control power supply (LENZE PSL or equivalent)
- LENZE Engineer / GDC parameterization software
- DIN rail mounting hardware and cable management accessories
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and Low Voltage Directive
- UL / cUL Listed – Recognized for North American industrial installations (verify current listing status)
- RoHS Compliant – Meets EU Directive 2011/65/EU on restriction of hazardous substances
- ISO 9001 – Manufactured under LENZE’s certified quality management system
- IEC 61800 – Designed in accordance with adjustable-speed electrical power drive systems standards
Quality Assurance & Sourcing
At Konmask.com, every LENZE module is sourced through verified industrial supply channels. Our quality process includes:
- Visual and dimensional inspection upon receipt
- Label and date-code verification against manufacturer records
- Functional power-on test where applicable
- Anti-static packaging and climate-controlled storage
- Full traceability documentation available on request
We do not source from grey-market or unverified brokers. All stock is available for immediate inspection by appointment.
How to Source This Part
- Add to Cart – Click the purchase button above to place your order directly online.
- Request a Quote – For volume orders (5+ units) or project BOM pricing, email support@konmask.com.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock items: contact us for ETA.
- Export & Cross-Border – We support international shipments with full commercial invoice and packing list documentation.
- Technical Pre-Sales Support – Our engineers can confirm compatibility with your existing LENZE drive configuration before purchase.
Application-Specific FAQ
Q: Is the EPM-S501.2A.10 compatible with all LENZE ECS drives?
A: It is designed for the ECS/EPM expansion slot family. Verify your drive’s expansion slot type against the LENZE EPM-S501 compatibility matrix before ordering.
Q: Can both analog outputs operate simultaneously and independently?
A: Yes. Each channel is independently configurable for voltage (±10 V) or current (0–20 mA) output via drive parameters.
Q: What software is needed to configure this module?
A: LENZE Engineer (LE) or Global Drive Control (GDC) software. Both are available from LENZE’s official software portal.
Q: Do you offer a warranty on this module?
A: Yes. Konmask.com provides a 12-month warranty against manufacturing defects on all stocked LENZE modules.
Q: Can this module be used as a replacement for a failed unit in an existing machine?
A: Yes, provided the host drive firmware version is compatible. Contact our technical team with your drive nameplate data for confirmation.
