Genuine OMRON C500-AD501 Analog Input Module | C500 Series – Verified Source
The OMRON C500-AD501 is a high-precision analog input module designed for the OMRON SYSMAC C500 Series Programmable Logic Controller (PLC) platform. Sourced directly through verified industrial supply channels, this module is ideal for engineers and procurement teams who demand authenticity, traceability, and reliable performance in mission-critical automation environments.
Technical Specifications
- Part Number / SKU: C500-AD501
- Brand: OMRON
- Series: SYSMAC C500
- Module Type: Analog Input Module
- Input Channels: 4 channels (voltage/current selectable)
- Input Signal Range: 0–10 V DC / 4–20 mA (channel-configurable)
- Resolution: 12-bit (0–4095)
- Conversion Speed: Approx. 2.5 ms/channel
- Isolation: Photocoupler isolation between channels and CPU bus
- Power Consumption: 5 V DC, 250 mA (from backplane)
- Operating Temperature: 0°C to 55°C
- Storage Temperature: −20°C to 75°C
- Humidity: 10%–90% RH (non-condensing)
- Weight: Approx. 1,230 g
- Compliance: CE, UL, cUL
Our 4-Step Quality Verification Process
Every OMRON C500-AD501 unit shipped from Konmask.com undergoes a rigorous 4-step inspection before dispatch:
- Step 1 – Origin Traceability: Serial number and date code verified against OMRON’s authorized distribution records.
- Step 2 – Physical Inspection: Housing, label, connector pins, and PCB markings examined for signs of counterfeit or refurbishment.
- Step 3 – Functional Bench Test: Module powered and analog I/O channels tested under load conditions to confirm specification compliance.
- Step 4 – Packaging & Documentation: Unit resealed with tamper-evident packaging; test report and certificate of conformity included on request.
Key Features & Benefits
- ✅ Genuine OMRON OEM part — not refurbished, not cloned
- ✅ 4-channel analog input with per-channel voltage/current selection
- ✅ 12-bit resolution for precise process variable monitoring
- ✅ Photocoupler isolation protects CPU from field-side noise and surges
- ✅ Drop-in compatible with existing C500 rack configurations — no rewiring required
- ✅ Long-term availability — stocked for MRO and legacy system support
- ✅ Fast global dispatch — same-day shipping on in-stock units
Typical Applications
- Process control: temperature, pressure, flow, and level monitoring via 4–20 mA transmitters
- Factory automation: analog feedback from servo drives, VFDs, and sensors
- Water treatment and HVAC systems requiring multi-channel analog acquisition
- Legacy SYSMAC C500 system maintenance, repair, and overhaul (MRO)
- OEM machine builders maintaining installed base equipment
Compatible System Components
- CPU Units: OMRON C500, C500F, C1000H, C2000H series CPUs
- Backplane / Racks: C500-BC051, C500-BC081, C500-BC101 and compatible expansion racks
- Power Supplies: C500-PS221, C500-PS211 series
- Programming Devices: OMRON CX-Programmer (legacy ladder logic support)
- Related I/O Modules: C500-DA501 (Analog Output), C500-ID212 (Digital Input), C500-OD212 (Digital Output)
Global Sourcing & Shipping Capabilities
Konmask.com operates as a specialist industrial automation parts supplier serving clients across Asia-Pacific, Europe, the Middle East, and the Americas. We maintain bonded warehouse stock and work with DHL Express, FedEx International Priority, and sea freight consolidators to ensure cost-effective, timely delivery regardless of order volume.
- Lead Time: In-stock units ship within 1–2 business days
- Minimum Order Quantity: 1 unit (bulk pricing available for 5+ units)
- Export Documentation: Commercial invoice, packing list, certificate of origin available
- Customs HS Code: 8537.10 (Boards, panels, consoles for electric control)
- Country of Origin: Japan (OMRON manufactured)
Certifications & Compliance Statement
The OMRON C500-AD501 carries the following certifications as issued by OMRON Corporation:
- CE Marking — compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed — recognized for use in North American industrial installations
- RoHS Compliant — manufactured under OMRON’s environmental compliance program
Konmask.com does not alter, relabel, or modify any OEM hardware. All units are sold as-manufactured by OMRON Corporation.
How to Order
- Confirm the part number: C500-AD501 matches your system’s slot and rack requirements.
- Select quantity and add to cart.
- For bulk orders (>5 units) or urgent requirements, contact us directly for a dedicated quote.
- Provide your shipping address and preferred freight method at checkout.
- Receive order confirmation with tracking number within 24 hours of dispatch.
📧 Email: [email protected]
📞 Phone / WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Authenticity & Trust FAQ
Q: How do I know this is a genuine OMRON part?
A: Every unit passes our 4-step verification process (see above). We provide serial number documentation and can supply a test report on request.
Q: Do you sell refurbished or repaired modules?
A: No. Konmask.com exclusively stocks new or factory-surplus (never repaired) OEM units. Refurbished stock is clearly labeled if ever offered separately.
Q: What warranty applies?
A: We offer a 12-month warranty against manufacturing defects. DOA (Dead on Arrival) units are replaced at no cost within 7 days of receipt.
Q: Can you source discontinued OMRON parts?
A: Yes. Our global sourcing network covers legacy and end-of-life OMRON components. Contact us with your full BOM for availability and pricing.
Q: Do you accept returns?
A: Yes, within 30 days of delivery for unused, unopened units in original packaging.
