OMRON NS5-MQ00-V2 Monochrome STN HMI Programmable Terminal | Replacement, Equivalent & Selection Guide
The OMRON NS5-MQ00-V2 is a 5.7-inch monochrome STN LCD programmable terminal from OMRON’s NS Series HMI line. Designed for industrial automation environments, it delivers reliable operator interface functionality with broad PLC compatibility. This page provides full technical specifications, verified replacement options, equivalent models, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
- Model: NS5-MQ00-V2
- Brand / Manufacturer: OMRON
- Series: NS Series (NS5)
- Display Type: Monochrome STN LCD
- Screen Size: 5.7 inch
- Resolution: 320 × 240 (QVGA)
- Backlight: EL (Electroluminescent)
- Communication Ports: RS-232C × 2, USB (Type-B, programming)
- Memory: Built-in flash memory
- Power Supply: DC 24 V
- Power Consumption: Approx. 10 W
- Operating Temperature: 0 – 50 °C
- Storage Temperature: −20 – 60 °C
- Protection Rating: IP65 (front panel)
- Weight: Approx. 1.0 kg
- Dimensions (W × H × D): 182 × 137 × 57 mm
- Programming Software: CX-Designer
- Certifications: CE, UL
Compatible Replacement & Equivalent Models
The following models are verified functional replacements or close equivalents for the NS5-MQ00-V2. Always confirm communication protocol and panel cutout dimensions before substitution.
- OMRON NS5-MQ01-V2 — Same platform, adds Ethernet port; direct upgrade path
- OMRON NS5-SQ00-V2 — 5.7″ STN, RS-232C only; functionally equivalent for basic applications
- OMRON NS5-SQ01-V2 — 5.7″ STN with Ethernet; suitable when network connectivity is required
- OMRON NS5-TQ00-V2 — 5.7″ TFT color upgrade; same form factor, enhanced visibility
- Weintek MT6050i — Third-party 5.7″ monochrome HMI; compatible with OMRON PLCs via Modbus/RS-232C
- Proface GP2301-LG41-24V — 5.7″ STN equivalent; requires driver configuration for OMRON protocol
Note: Third-party replacements require protocol driver setup. Contact [email protected] for compatibility verification.
Why Choose the Original Model
- Native OMRON Protocol Support: Plug-and-play with OMRON CJ, CS, CP, and NJ/NX series PLCs — no driver configuration required.
- CX-Designer Ecosystem: Full project compatibility with OMRON’s CX-One suite; existing screen projects transfer without modification.
- Proven Industrial Reliability: IP65 front panel, wide operating temperature range, and EL backlight rated for continuous industrial duty.
- Long-term Parts Availability: OMRON maintains spare parts and repair services for NS Series; reduces lifecycle risk.
- Regulatory Compliance: CE and UL certified; meets requirements for EU machinery directive and North American installations.
Typical Applications
- Machine tool operator panels and CNC status displays
- Conveyor and material handling control interfaces
- Packaging line HMI stations
- Water treatment and HVAC monitoring panels
- Food & beverage processing equipment (washdown-adjacent, front IP65)
- Retrofit and upgrade of legacy NS5 installations
System Compatibility
The NS5-MQ00-V2 communicates natively with the following OMRON PLC families via RS-232C:
- OMRON CJ1 / CJ2 Series
- OMRON CS1 Series
- OMRON CP1 Series
- OMRON NJ / NX Series (via serial adapter)
- OMRON C200H / CVM1 (legacy, via protocol converter)
Third-party PLC connectivity (Mitsubishi, Siemens, Schneider) is possible via Modbus RTU or custom RS-232C drivers configured in CX-Designer.
Selection Guide
Use the table below to select the correct NS5 variant for your application:
- NS5-MQ00-V2 — Monochrome STN, RS-232C only → Cost-sensitive, no network required
- NS5-MQ01-V2 — Monochrome STN, RS-232C + Ethernet → Network monitoring required
- NS5-TQ00-V2 — Color TFT, RS-232C only → Improved operator visibility, same budget tier
- NS5-TQ01-V2 — Color TFT, RS-232C + Ethernet → Full-featured, networked color HMI
- NS8 / NS10 / NS12 Series — Larger screen (8″–12″) → Complex process visualization, multi-screen projects
Key selection criteria: screen size, color vs. monochrome, communication ports (serial / Ethernet), and CX-Designer project compatibility.
Quality Assurance & Sourcing
- Source: Authorized distributor stock and verified surplus channels
- Inspection: Each unit inspected for physical integrity, label authenticity, and firmware version prior to shipment
- Warranty: 90-day functional warranty on all units; extended warranty available on request
- Traceability: Batch records and serial number documentation provided on request
- Anti-counterfeit: All OMRON units sourced with original packaging where available; counterfeit screening applied
How to Order
- Online: Add to cart directly on this page — stock availability shown in real time
- Email RFQ: [email protected] — include quantity, required delivery date, and destination country
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock orders ship within 1–3 business days; sourced orders 7–15 business days
- Shipping: DHL / FedEx / UPS international express; sea freight available for bulk orders
- Payment: T/T bank transfer, PayPal, credit card (via Shopify Payments)
Replacement & Compatibility FAQ
Q: Can the NS5-MQ00-V2 be replaced by the NS5-MQ01-V2?
A: Yes. The NS5-MQ01-V2 is a direct functional upgrade — same panel cutout, same RS-232C ports, plus an added Ethernet port. Existing CX-Designer projects transfer without modification.
Q: Is the NS5-MQ00-V2 compatible with Mitsubishi PLCs?
A: Not natively. A Modbus RTU driver or RS-232C protocol converter is required. Contact us for recommended converter models.
Q: What software is needed to program the NS5-MQ00-V2?
A: OMRON CX-Designer (part of the CX-One suite). Version 3.x and above support NS5-V2 series.
Q: Is the EL backlight replaceable?
A: Yes, as a service part. OMRON part number available on request. Typical EL backlight lifespan is 10,000–20,000 hours.
Q: Do you supply new or refurbished units?
A: Both. New (original packaging) and tested-good surplus units are available. Condition is clearly stated on each listing.
