RITTAL SCM17EG1-R — RGB/DVI Display Interface Module | SM 6450.160 Series
Engineering Background
RITTAL GmbH & Co. KG, headquartered in Herborn, Germany, is a global leader in industrial enclosure systems, power distribution, and climate control infrastructure. The SCM17EG1-R is part of RITTAL’s Smart Monitoring and Control (SM) platform — engineered to bridge legacy analog RGB display signals with modern DVI digital interfaces in demanding industrial environments. This module is deployed across machine tool OEMs, process automation panels, and critical infrastructure control rooms where display signal integrity is non-negotiable.
Product Positioning
The SCM17EG1-R (Part No. 6450.160) is a panel-mount RGB-to-DVI signal conversion and interface module designed for integration into RITTAL SM enclosure systems. It enables engineers to retrofit or upgrade HMI display chains without replacing existing RGB-output controllers — protecting capital investment while achieving DVI-quality output. Konmask.com supplies this module as verified OEM stock, sourced through authorized industrial distribution channels with full traceability.
Complete Technical Specifications
- Manufacturer: RITTAL GmbH & Co. KG
- Part Number: 6450.160
- Model: SCM17EG1-R
- Series: SM (Smart Monitoring) Platform — 6450 Series
- Function: RGB / DVI Display Interface Module
- Signal Input: Analog RGB (VGA-compatible, HD-15 connector)
- Signal Output: DVI-D (Digital Visual Interface — Digital only)
- Max Input Resolution: Up to 1280 × 1024 (SXGA)
- Form Factor: Panel-mount module for RITTAL SM enclosure integration
- Power Supply: Via RITTAL SM backplane or direct DC rail within enclosure
- Weight: 2,920 g (as shipped)
- Compliance: CE marked; designed to EN/IEC industrial standards
- Country of Origin: Germany
- HS Code: 8537.10 (Boards, panels, consoles for electric control)
Proven Application Environments
- CNC machine tool HMI display upgrades (Siemens, Fanuc, Mitsubishi controller panels)
- Process automation control rooms requiring DVI output from legacy RGB sources
- RITTAL SM enclosure-based operator workstations and supervisory terminals
- Pharmaceutical and food-grade production line control panels (IP-rated enclosure integration)
- Power generation and utilities SCADA display infrastructure
- OEM panel builders standardizing on DVI display chains for new machine builds
- Retrofit projects replacing failed display interface modules in existing RITTAL SM installations
Engineering Advantages
- Signal Fidelity: Converts analog RGB to clean DVI-D output, eliminating signal degradation over long cable runs common in large enclosures.
- Backward Compatibility: Accepts standard RGB inputs from existing PLCs and HMI controllers — no controller-side firmware or hardware changes required.
- Enclosure-Native Design: Engineered specifically for RITTAL SM panel integration; mounting dimensions and connector positions align with RITTAL’s modular enclosure grid.
- Reduced Downtime Risk: Drop-in replacement for failed display interface modules; no re-engineering of signal chain required.
- Industrial Robustness: Designed for continuous operation in EMI-rich environments typical of motor drives, servo amplifiers, and high-current switchgear panels.
- Capital Protection: Extends the service life of existing RGB-output HMI controllers, deferring costly controller replacement cycles.
System Architecture & Signal Flow
The SCM17EG1-R sits at the display interface layer of the RITTAL SM control architecture:
- ① Input Stage: Analog RGB signal received from PLC/HMI controller output via standard HD-15 (VGA) connector
- ② Conversion Stage: Onboard analog-to-digital conversion with signal conditioning, sync separation, and pixel clock recovery
- ③ Output Stage: DVI-D digital signal delivered to panel-mount industrial monitor or remote display unit
- ④ Power Stage: Supplied via RITTAL SM backplane DC rail — no external PSU required in standard SM enclosure installations
- ⑤ System Integration: Compatible with RITTAL SM 6450 series display and monitoring modules; plug-compatible with existing SM backplane positions
Sourcing & Quality Verification
- Stock Type: OEM / Original manufacturer stock — not refurbished, not aftermarket clone
- Traceability: Each unit ships with manufacturer part label (6450.160) and batch traceability documentation available upon request
- Inspection: Pre-shipment visual and functional inspection performed by Konmask technical team prior to dispatch
- Packaging: Original RITTAL anti-static packaging or equivalent ESD-safe packaging for international transit
- Certification: CE marked; country of origin Germany declared on all export documentation
- Warranty: 12-month Konmask supply warranty against manufacturing defects from date of shipment
Procurement Process
- Step 1 — Inquiry: Submit RFQ via Konmask.com product page or email support@konmask.com with quantity and required delivery date
- Step 2 — Quotation: Konmask issues formal quotation within 1 business day including unit price, lead time, and shipping options (DHL / FedEx / sea freight)
- Step 3 — Order Confirmation: Purchase order accepted via email confirmation, Shopify checkout, or bank transfer (T/T)
- Step 4 — Shipment: Dispatched via DHL Express / FedEx International Priority with full tracking; export documentation (commercial invoice, packing list, COO, HS 8537.10) included
- Step 5 — After-Sales Support: Technical support available post-delivery; replacement or credit issued for verified defective units within warranty period
Technical FAQ
Q: Is the SCM17EG1-R compatible with non-RITTAL enclosures?
A: The module can be panel-mounted in third-party enclosures provided the cutout dimensions and DC power supply requirements are met. Contact Konmask for dimensional drawings and power specifications.
Q: What is the maximum RGB input resolution supported?
A: The module supports standard industrial RGB resolutions up to 1280 × 1024 (SXGA). Confirm compatibility with your specific HMI controller output specification before ordering.
Q: Can this module replace a failed unit in an existing RITTAL SM installation?
A: Yes. The SCM17EG1-R is a direct replacement for the 6450.160 position in RITTAL SM display chains. No reconfiguration of the enclosure backplane is required.
Q: Do you provide export documentation for customs clearance?
A: Yes. All international shipments include commercial invoice, packing list, and certificate of origin. HS code 8537.10 is declared. Additional documentation (Form E, EUR.1, FORM A) available upon request.
Q: What is the lead time for in-stock units?
A: In-stock units ship within 2–3 business days of order confirmation. Lead time for non-stock orders is quoted individually based on current supply chain status.
Q: Is the unit new or refurbished?
A: All units supplied by Konmask are new OEM stock. We do not supply refurbished, repaired, or aftermarket substitute components.
