SCHNEIDER BMEAHI0812 Analog Input Module – Modicon M580 Series
Imagine a critical process line where temperature, pressure, or flow signals from field sensors never reach the controller. Without a reliable analog input module, your PLC operates blind — unable to regulate setpoints, trigger alarms, or maintain product quality. Unplanned shutdowns, off-spec output, and safety incidents become inevitable. The SCHNEIDER BMEAHI0812 eliminates this vulnerability by delivering precise, noise-immune analog signal acquisition directly into the Modicon M580 backplane, keeping your process under continuous, accurate control.
Within the Modicon M580 ePAC ecosystem — Schneider Electric’s flagship Ethernet-native process automation controller — the BMEAHI0812 occupies a pivotal role as the primary high-density analog front-end. Its 8-channel architecture, combined with 16-bit resolution and universal signal compatibility, positions it as the preferred choice for process industries worldwide where measurement accuracy and system uptime are non-negotiable. As global manufacturing shifts toward IIoT-ready architectures, the M580 platform and its I/O modules like the BMEAHI0812 are at the center of digital transformation projects across oil & gas, water treatment, and advanced manufacturing.
Technical Specifications
- Part Number: BMEAHI0812
- Brand: Schneider Electric (Modicon)
- Series: Modicon M580 ePAC
- Module Type: Analog Input Module
- Number of Channels: 8 channels
- Signal Types: Voltage (±10 V, 0–10 V) and Current (0–20 mA, 4–20 mA)
- Resolution: 16-bit
- Isolation: Channel-to-bus isolation
- Communication Bus: Modicon M580 local rack bus (X80 backplane)
- Operating Temperature: 0 °C to 60 °C
- Mounting: M580 / X80 rack-mount
- Certifications: CE, UL, cUL (verify current datasheet for full listing)
Note: Always verify specifications against the official Schneider Electric datasheet before engineering design. Konmask.com does not modify or fabricate technical parameters.
Key Features & Benefits
- 8 Universal Analog Channels: Supports both voltage and current inputs on each channel, reducing the need for separate module types and simplifying BOM management.
- 16-Bit High Resolution: Delivers fine-grained measurement accuracy critical for tight process control loops in chemical, pharmaceutical, and energy applications.
- Seamless M580 Backplane Integration: Plug-and-play installation on any M580 or X80 rack with automatic module recognition by Unity Pro / EcoStruxure Control Expert.
- Channel-to-Bus Isolation: Protects the controller and other modules from field-side transients and ground loops, enhancing system reliability.
- Hot-Swap Capable: Supports module replacement under power (rack-dependent), minimizing maintenance downtime in 24/7 production environments.
- Diagnostics & Fault Detection: Built-in channel-level diagnostics report open-circuit, over-range, and under-range conditions directly to the CPU for rapid fault isolation.
- IIoT-Ready Platform: As part of the M580 ePAC, data from this module is natively accessible via Ethernet/IP and Modbus TCP for SCADA, historian, and cloud integration.
Industry & Equipment Applications
- Oil & Gas: Pipeline pressure and flow monitoring, wellhead control panels, compressor station automation.
- Water & Wastewater Treatment: pH, turbidity, dissolved oxygen, and level signal acquisition in treatment plant PLCs.
- Power Generation & Utilities: Turbine inlet temperature monitoring, boiler drum level control, substation automation.
- Chemical & Petrochemical: Reactor temperature profiling, distillation column control, batch process management.
- Food & Beverage: CIP temperature validation, pasteurization control, filling line pressure regulation.
- Automotive Manufacturing: Paint booth climate control, press force monitoring, conveyor tension feedback.
- Building Automation (Large Facilities): HVAC chiller plant control, energy metering integration.
System Integration & Compatible Parts
The BMEAHI0812 is designed for use within the Schneider Electric Modicon M580 and X80 I/O ecosystem. Typical compatible components include:
- CPUs: BMEP58xxxx series (M580 ePAC processors)
- Power Supplies: BMXCPS2000 / BMXCPS3500 series rack power supplies
- Racks: BMXXBP0400 / BMXXBP0800 / BMEXBP0400 series backplanes
- Communication Modules: BMENOC0301 (Ethernet network option), BMENOS0300
- Analog Output Modules: BMEAHO0412 (complementary AO module for closed-loop control)
- Programming Software: EcoStruxure Control Expert (formerly Unity Pro) v14.0+
- Field Wiring: BMXFTB2010 / BMXFTB2000 series terminal blocks
Contact Konmask.com for cross-reference assistance and complete BOM support for your M580 project.
Our Quality Assurance Process
Every SCHNEIDER BMEAHI0812 unit sourced and supplied by Konmask.com undergoes a rigorous multi-stage verification process before shipment:
- Authenticity Verification: Visual inspection of labels, firmware version stamps, and holographic markings against Schneider Electric’s genuine product standards.
- Functional Pre-Check: Where applicable, modules are powered and checked for LED status indication and communication response.
- Packaging Integrity: Anti-static packaging, moisture barrier bags, and shock-absorbing foam inserts are used for all shipments.
- Documentation: Each order is accompanied by a packing list and, upon request, a certificate of conformity or test report.
- Traceability: Batch and serial number records are maintained for full supply chain traceability.
How to Order
- Submit an Inquiry: Use the contact form on this page or email support@konmask.com with your required quantity and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and availability confirmation.
- Order Confirmation: Review and approve the proforma invoice. Payment terms are discussed at this stage.
- Shipment & Tracking: We arrange export packaging and provide a tracking number upon dispatch. DHL, FedEx, and sea freight options available.
- After-Sales Support: Our technical team remains available post-delivery for integration questions and warranty claims.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- Verified Supply Chain: We work with authorized distributors and reputable secondary market sources, with strict counterfeit screening.
- Global Export Experience: Serving engineering firms, system integrators, and MRO teams across Asia, Europe, the Middle East, and the Americas.
- Fast Response: Dedicated account managers respond to RFQs within 24 hours, with expedited options for urgent shutdowns.
- Technical Depth: Our team understands M580 architecture — we can advise on compatibility, firmware, and system configuration, not just ship a box.
- Competitive Pricing: Volume discounts available for project orders and long-term supply agreements.
Frequently Asked Questions
Q: Is the BMEAHI0812 compatible with the older Modicon M340 platform?
A: No. The BMEAHI0812 is designed exclusively for the Modicon M580 and X80 I/O backplane architecture. For M340 applications, the equivalent module family is the BMXAMI series.
Q: Can each channel be configured independently for voltage or current input?
A: Yes. Each of the 8 channels can be individually configured via EcoStruxure Control Expert software for the desired signal type (voltage or current), range, and filter settings.
Q: What is the typical lead time for the BMEAHI0812?
A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. For larger quantities or project orders, contact us for a confirmed delivery schedule.
Q: Do you provide a warranty on this module?
A: Yes. Konmask.com provides a standard warranty on all supplied modules. Warranty terms are specified in the sales agreement. Please contact us for details.
Q: Can you supply other modules in the Modicon M580 series?
A: Absolutely. We maintain stock and sourcing capability across the full M580 I/O range, including digital I/O, analog output, communication, and specialty modules. Submit an RFQ with your complete BOM.
Q: Is export documentation available for customs clearance?
A: Yes. We provide commercial invoices, packing lists, and certificates of origin as standard. Additional documentation (e.g., MSDS, test reports) is available upon request.
