Schneider Electric BMXFCW301S Shielded Cord Set | Replacement, Equivalent & Selection Guide
The Schneider Electric BMXFCW301S is a shielded cord set designed for use with the Modicon M340 PLC platform. This accessory ensures reliable, noise-resistant signal transmission in demanding industrial automation environments. Whether you are sourcing an original unit, seeking a compatible replacement, or evaluating equivalent alternatives, this guide provides the technical detail and selection criteria you need.
Technical Specifications
- Part Number: BMXFCW301S
- Manufacturer: Schneider Electric
- Series: Modicon M340
- Type: Shielded Cord Set
- Cable Length: 3 m (approx.)
- Shielding: Full electromagnetic shielding for noise immunity
- Connector Type: Compatible with M340 communication/I/O modules
- Operating Temperature: -25°C to +70°C (typical industrial range)
- Standards Compliance: CE, RoHS
- Weight: ~100 g
Compatible Replacement & Equivalent Models
When the original BMXFCW301S is unavailable or out of budget, the following alternatives may be considered based on connector type, cable length, and shielding specification:
- BMXFCW151S – Schneider Electric shielded cord set, 1.5 m variant (shorter run applications)
- BMXFCW501S – Schneider Electric shielded cord set, 5 m variant (longer run applications)
- TSXCAP030 – Legacy Schneider cord set with compatible pinout for certain M340 modules
- Third-party shielded cables – Must match connector pinout, impedance, and shielding class; verify with module datasheet before use
Note: Always verify connector compatibility and cable length against your specific M340 module before substituting.
Why Choose the Original BMXFCW301S
- Factory-tested and certified for Modicon M340 platform compatibility
- Full EMI/RFI shielding ensures signal integrity in high-noise environments
- Plug-and-play installation — no field termination required
- Guaranteed dimensional and electrical compliance with Schneider Electric module specifications
- Backed by Schneider Electric’s global warranty and support network
Typical Applications
- Modicon M340 PLC communication module wiring
- Industrial machine automation panels
- Process control cabinets in manufacturing plants
- Building management and HVAC control systems
- Water treatment and utilities automation
- Automotive assembly line control systems
System Compatibility
- Primary Platform: Schneider Electric Modicon M340 (BMX series)
- Compatible Modules: BMX communication, analog, and specialty I/O modules requiring shielded cord sets
- Software: Unity Pro / EcoStruxure Control Expert (no software dependency for hardware accessory)
- Rack Compatibility: BMX XBP series backplanes
Selection Guide
Use the following criteria to select the correct cord set for your application:
- Cable Length: Measure the physical distance between the module and the connected device; add 15–20% slack. Choose BMXFCW151S (1.5 m), BMXFCW301S (3 m), or BMXFCW501S (5 m) accordingly.
- Shielding Requirement: For environments with variable-frequency drives (VFDs), servo drives, or high-current switching, always select the shielded (S-suffix) variant.
- Connector Type: Confirm the target module’s port specification in the Schneider Electric module datasheet before ordering.
- Quantity: Order one cord set per module port requiring a shielded connection.
Quality Assurance & Sourcing
- All units sourced by Konmask.com are verified against manufacturer part numbers and inspected upon receipt.
- We supply genuine Schneider Electric components — no counterfeit or grey-market stock.
- Traceability documentation available upon request for MRO and OEM procurement teams.
- Stock status updated regularly; contact us for lead time on bulk or urgent orders.
How to Order
- Online: Add to cart directly from this page at Konmask.com
- Email: support@konmask.com — include part number, quantity, and delivery location
- Phone/WhatsApp: +0086 19859288691
- Bulk / OEM Pricing: Request a quote via email for orders of 5+ units
Replacement & Compatibility FAQ
Q: Can I use a standard unshielded cable instead of the BMXFCW301S?
A: Not recommended. Unshielded cables in industrial environments are susceptible to EMI interference, which can cause communication errors or module faults.
Q: Is the BMXFCW301S compatible with older Modicon Premium or Quantum PLCs?
A: No. This cord set is designed specifically for the M340 (BMX) platform. For Premium or Quantum systems, refer to TSX or 140-series accessories.
Q: What is the difference between BMXFCW301S and BMXFCW301?
A: The “S” suffix denotes the shielded version. The non-S variant lacks full EMI shielding and is not recommended for electrically noisy environments.
Q: Can Konmask.com provide a certificate of conformity?
A: Yes. Certificates of conformity and test reports are available upon request for qualified buyers.
Q: What is the lead time for BMXFCW301S?
A: In-stock orders typically ship within 1–3 business days. Contact us for current availability.
