Schneider Electric 170AAI14000 Distributed Analog Input Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 170AAI14000 is a 16-channel distributed analog input module engineered for the Modicon Quantum automation platform. Delivering high-accuracy analog signal acquisition across 4–20 mA, 0–20 mA, 1–5 V, and 0–10 V inputs, it is a cornerstone component in industrial process control, SCADA, and DCS architectures. This page is a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing the 170AAI14000 or its functional equivalents.
Technical Specifications
- Part Number: 170AAI14000
- Brand: Schneider Electric (Modicon)
- Series: Modicon Quantum Distributed I/O
- Module Type: Analog Input
- Number of Channels: 16 analog input channels
- Input Signal Types: 4–20 mA / 0–20 mA / 1–5 V / 0–10 V (configurable per channel)
- Resolution: 12-bit
- Communication: Modbus Plus / Modbus RTU (via Quantum head adapter)
- Power Supply: 24 VDC (bus-supplied)
- Operating Temperature: 0°C to 60°C
- Mounting: DIN rail / panel mount via Quantum I/O drop
- Weight: 220 g
- Country of Origin: France
- Compliance: CE, UL, cUL
Compatible Replacement & Equivalent Models
If the 170AAI14000 is discontinued, on long lead time, or outside budget, the following models offer functional equivalence or direct drop-in replacement capability:
- 170AAI14001 – Revised version of 170AAI14000; same form factor and pinout, enhanced diagnostics. Firmware update may be required.
- 170AAI03000 – Schneider Electric Modicon Quantum 8-channel analog input; half channel count, same bus architecture.
- 140AII33000 – Modicon Premium analog input module; requires adapter for Quantum rack integration.
- BMXAMI0810 – Modicon M340 8-channel analog input; different platform, requires engineering review before substitution.
- Third-party equivalents: Prosoft MVI46-MCM, Wago 750-452 — signal-level compatible; bus adapter required.
Always verify firmware version, bus compatibility, and channel count before substituting. Contact support@konmask.com for a free compatibility check.
Why Choose the Original 170AAI14000
- ✅ Native Modicon Quantum bus integration — zero configuration overhead
- ✅ Proven 12-bit resolution for precise process variable measurement
- ✅ Full Schneider Electric firmware and Unity Pro / Concept / ProWORX software support
- ✅ Backward compatible with all legacy Quantum I/O drops
- ✅ Widely stocked — reduces procurement risk for MRO and capital projects
- ✅ CE, UL, cUL certified for global deployment
Typical Applications
- Oil & gas process monitoring — pressure, temperature, and flow measurement
- Water treatment plant SCADA systems
- Power generation and distribution control
- Chemical plant distributed control systems (DCS)
- Building automation and HVAC control loops
- Food & beverage production line monitoring
- Pharmaceutical batch process control
System Compatibility
- PLC Platform: Modicon Quantum (compatible with 140-series head adapters: 170ENT11001, 170ENT11002, etc.)
- Programming Software: Unity Pro, Concept, ProWORX
- Communication Protocols: Modbus Plus, Modbus RTU, Ethernet/IP (via head adapter)
- I/O Drop Compatibility: All standard Modicon Quantum distributed I/O drops
- Not compatible with: Modicon M340, M580, or Premium racks without adaptation hardware
Selection Guide
Use the criteria below to select the right analog input module for your Quantum system:
- Need 16 channels, 4–20 mA, Quantum bus? → 170AAI14000 ✅ (this product)
- Need 8 channels only? → 170AAI03000
- Need enhanced diagnostics on same form factor? → 170AAI14001
- Need HART protocol support? → Contact us for HART-compatible Quantum I/O options
- Migrating to M580 platform? → BMENOI0200 or BMXAMI0810 series (platform migration required)
- Budget-sensitive MRO replacement? → Ask about certified refurbished 170AAI14000 stock
Quality Assurance & Sourcing
- 🔍 All units inspected and functionally tested prior to shipment
- 📦 Original or equivalent OEM packaging maintained
- 🏭 Sourced from authorized distributors and verified secondary market channels
- 📄 Certificate of conformity available upon request
- 🔄 30-day return policy for unused, unopened items
- 🌍 Worldwide shipping via DHL, FedEx, and UPS Express
How to Order
- Add the 170AAI14000 to your cart and proceed to checkout, or
- Email support@konmask.com with your PO or RFQ, or
- Call / WhatsApp: +0086 19859288691 for urgent requirements
- Bulk orders (>5 units) qualify for volume pricing — request a quote
Replacement & Compatibility FAQ
Q: Is the 170AAI14000 still in production?
A: Schneider Electric has transitioned some Quantum I/O lines. Contact us to confirm current availability and lead times.
Q: Can I use a 170AAI14001 as a direct replacement?
A: Yes. The 170AAI14001 shares the same form factor and pinout. A firmware update may be required depending on your head adapter revision.
Q: Do you supply certified refurbished units?
A: Yes. All refurbished units are tested to OEM specifications and include a 90-day warranty.
Q: What is the lead time for new stock?
A: In-stock orders ship within 1–3 business days. Contact us for real-time stock levels.
Q: Can you assist with Quantum to M580 migration?
A: Yes. Our engineering team provides migration consultation. Email us for a project assessment.
