Industrial Network Bridge Solution – Schneider Electric NW-BM85-C002 | Modicon Quantum
Where This Product Is Used
The Schneider Electric NW-BM85-C002 Bridge Multiplexor Module is purpose-built for industrial environments where reliable, high-speed communication between Modicon Quantum PLC racks and remote I/O drops is mission-critical. Typical deployment scenarios include:
- Oil & Gas Processing Plants – Bridging remote field I/O panels to central Quantum PLC controllers across long cable runs in hazardous-area installations.
- Water & Wastewater Treatment Facilities – Multiplexing multiple I/O segments over a single communication backbone to reduce wiring costs and improve SCADA data integrity.
- Automotive Assembly Lines – Synchronizing distributed Quantum racks across multi-zone production cells where deterministic communication latency is required.
- Power Generation & Utilities – Connecting substation RTUs and protection relay panels into a unified Modicon Quantum control architecture.
- Pharmaceutical & Food Processing – Supporting validated, redundant control networks in GMP-regulated environments where network segmentation is mandatory.
Technical Specifications
- Part Number: NW-BM85-C002
- Series: Modicon Quantum
- Module Type: Bridge Multiplexor Module
- Manufacturer: Schneider Electric
- Form Factor: Single-slot Quantum backplane module
- Communication Protocol: Modbus Plus (MB+) / S908 Remote I/O
- Network Ports: Dual RJ-45 / BNC (model-dependent configuration)
- Max Remote Drop Distance: Up to 1,800 m (5,900 ft) with repeaters
- Operating Temperature: 0 °C to +60 °C (32 °F to 140 °F)
- Storage Temperature: -40 °C to +85 °C
- Relative Humidity: 5% to 95% non-condensing
- Power Consumption: Supplied via Quantum backplane (5 VDC)
- Weight: 1,250 g
- Certifications: CE, UL, cUL
- Country of Origin: France / USA (Schneider Electric manufacturing)
Why Engineers Specify This Model
- Proven Modicon Quantum Ecosystem Compatibility – Designed exclusively for the Quantum backplane; no adapter or converter required, ensuring plug-and-play integration with existing Quantum infrastructure.
- Multiplexed I/O Topology – Allows a single module to manage multiple remote I/O drops, dramatically reducing the number of head-end communication cards and associated wiring costs.
- Deterministic Scan Cycle – Maintains consistent, predictable I/O scan times critical for process control loops and safety-instrumented systems (SIS).
- Long-Distance Reach – Supports extended cable runs suitable for large plant footprints without signal degradation.
- Hot-Standby Ready – Compatible with Quantum Hot-Standby (HSB) redundancy configurations for continuous process availability.
- Simplified Network Diagnostics – Onboard LED status indicators enable rapid fault isolation without specialized test equipment.
Complete System Bill of Materials
For a fully operational Modicon Quantum remote I/O bridge system, engineers typically specify the following alongside the NW-BM85-C002:
- Modicon Quantum CPU Module (e.g., 140CPU65160 / 140CPU67160)
- Quantum Power Supply Module (e.g., 140CPS11420 / 140CPS21400)
- Quantum Backplane / Rack (e.g., 140XBP01600 – 16-slot)
- Remote I/O Drop Adapter (e.g., 140CRA93100)
- Modbus Plus Network Cable & Connectors (e.g., 990NAD21100)
- Quantum Discrete I/O Modules (e.g., 140DDI35300 / 140DDO35300)
- Quantum Analog I/O Modules (e.g., 140ACI04000 / 140ACO13000)
Contact [email protected] for a complete BOM quotation tailored to your project.
Compliance & Industry Standards
- CE Marking – Compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed – Recognized for use in North American industrial installations
- IEC 61131-2 – Programmable controller hardware standard compliance
- RoHS Compliant – Restriction of Hazardous Substances Directive
- ATEX / IECEx – Consult factory for zone-rated installation guidance
Quality Assurance & Sourcing
Every NW-BM85-C002 unit supplied by Konmask.com undergoes a rigorous incoming inspection process:
- Visual inspection for physical damage, label authenticity, and date codes
- Functional power-on verification where applicable
- Anti-static packaging and climate-controlled storage
- Traceability documentation available upon request
We source exclusively from authorized distributors, OEM surplus channels, and verified industrial resellers. Counterfeit-free guarantee backed by our sourcing policy.
How to Source This Part
Ready to order the Schneider Electric NW-BM85-C002? Here’s how to get started:
- Request a Quote: Email [email protected] with your required quantity and delivery timeline.
- Phone / WhatsApp: +0086 19859288691 – speak directly with our technical sales team.
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders typically 5–15 business days.
- Shipping: DHL Express, FedEx International Priority, and sea freight options available worldwide.
- Payment: T/T (Wire Transfer), PayPal, and trade credit terms for qualified accounts.
Application-Specific FAQ
Q: Is the NW-BM85-C002 compatible with Modicon Premium or M340 PLCs?
A: No. This module is designed exclusively for the Modicon Quantum backplane architecture. For Premium or M340 systems, different communication modules are required.
Q: Can this module be used in a Hot-Standby redundancy configuration?
A: Yes. The NW-BM85-C002 is compatible with Quantum Hot-Standby (HSB) setups when paired with the appropriate HSB CPU and cabling.
Q: What is the maximum number of remote I/O drops supported?
A: The S908 Remote I/O network supports up to 31 drops per head-end adapter. Consult your network topology design for specific drop counts per NW-BM85-C002 instance.
Q: Do you provide a warranty on this module?
A: Yes. Konmask.com offers a 90-day functional warranty on all modules. Extended warranty options are available — contact us for details.
Q: Can I return a module if it doesn’t fit my application?
A: We accept returns within 30 days of delivery for unused, uninstalled modules in original packaging. Contact [email protected] to initiate an RMA.
