Schneider Electric XBTF024610 Membrane Keypad | Replacement, Equivalent & Selection Guide
The Schneider Electric XBTF024610 is a membrane keypad (keyboard overlay) designed for the XBTF series HMI operator panels. This page serves as a comprehensive selection and sourcing reference for engineers, maintenance teams, and procurement specialists seeking the original part, compatible replacements, or equivalent alternatives.
Technical Specifications
| Part Number | XBTF024610 |
| Manufacturer | Schneider Electric |
| Series | XBTF (Magelis HMI) |
| Type | Membrane Keypad / Keyboard Overlay |
| Application | HMI Operator Panel – XBTF Series |
| Interface | Tactile membrane switch array |
| Construction | Multi-layer polyester membrane |
| IP Rating | IP65 (front face, panel-mounted) |
| Operating Temperature | 0°C to +55°C |
| Compatibility | Schneider Electric XBTF series HMI terminals |
| Country of Origin | France / China (OEM) |
Compatible Replacement & Equivalent Models
When the original XBTF024610 is unavailable or discontinued, the following models may serve as functional equivalents depending on your HMI panel version. Always verify mechanical fit and key layout before installation.
- XBTF024510 – Earlier revision keypad for XBTF series; verify key count and connector pinout
- XBTF024710 – Later revision; check firmware compatibility with your HMI terminal
- XBTF032110 – Alternative XBTF keypad variant; confirm panel model compatibility
- Generic XBTF-series OEM membrane – Third-party overlays with matching key matrix; suitable for non-critical applications
- Siemens TP177 / TP270 Keypad – Cross-brand alternative for comparable compact HMI panels (requires panel replacement)
Note: Konmask.com recommends using the original Schneider Electric XBTF024610 for safety-critical and regulated environments.
Why Choose the Original XBTF024610
- ✅ Guaranteed fit – Designed specifically for XBTF series HMI terminals; no modification required
- ✅ Certified quality – Manufactured to Schneider Electric’s IEC/UL standards
- ✅ Long service life – Rated for millions of actuations under industrial conditions
- ✅ Full traceability – Authentic part with Schneider Electric documentation and warranty
- ✅ Regulatory compliance – Suitable for CE-marked and UL-listed control panel builds
Typical Applications
- Machine tool control panels and CNC operator interfaces
- Packaging line HMI terminals requiring keypad replacement
- Water treatment and utilities SCADA operator stations
- Food & beverage processing lines with IP65 panel requirements
- Preventive maintenance replacement in aging XBTF-series installations
System Compatibility
The XBTF024610 membrane keypad is compatible with the following Schneider Electric HMI platforms:
- Magelis XBTF series – Primary target platform
- Vijeo Designer – HMI programming software environment
- Modicon M340 / M580 PLC systems – When paired with XBTF HMI terminals
- Altivar drive panels – Where XBTF HMI is used as a remote operator interface
Verify your exact XBTF panel model number before ordering to confirm keypad layout compatibility.
Selection Guide
Use the following criteria to select the correct membrane keypad for your application:
- Step 1 – Identify your HMI model: Locate the model label on the rear of your XBTF panel (e.g., XBTF024110, XBTF032110)
- Step 2 – Match the keypad part number: Cross-reference the panel model with the keypad suffix (e.g., XBTF024610 for XBTF024x panels)
- Step 3 – Verify key layout: Count function keys (F-keys), numeric keys, and navigation keys; compare with your existing keypad
- Step 4 – Check connector type: Confirm the ribbon cable connector pitch and pin count match your panel’s internal connector
- Step 5 – Consider environment: For harsh environments, confirm IP rating and chemical resistance of the membrane surface
Not sure which part you need? Contact our technical team with your panel model number for a free selection consultation.
Quality Assurance & Sourcing
All Schneider Electric parts supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes:
- Visual inspection for membrane integrity and connector condition
- Packaging verification against Schneider Electric OEM standards
- Batch traceability documentation available on request
We supply both new original and new surplus stock. Lead times and availability are confirmed at time of inquiry.
How to Order
- Add the XBTF024610 to your cart and proceed to checkout, or
- Email support@konmask.com with your purchase order or RFQ
- For bulk orders (>5 units) or urgent requirements, call +0086 19859288691 for priority handling
- Provide your shipping address and preferred Incoterm (EXW, FOB, DDP) for international orders
We accept T/T bank transfer, PayPal, and major credit cards. Export documentation (CO, packing list, commercial invoice) provided for all international shipments.
Replacement & Compatibility FAQ
Q: Can I use a generic membrane keypad instead of the original XBTF024610?
A: Generic overlays may fit physically but often lack the precise key matrix layout required by the XBTF panel firmware. For production-critical systems, use the original Schneider Electric part.
Q: Is the XBTF024610 still in production?
A: Schneider Electric periodically revises HMI accessories. Contact us to confirm current production status and available stock.
Q: What is the lead time for the XBTF024610?
A: In-stock orders ship within 1–3 business days. Out-of-stock items typically have a 2–6 week lead time depending on Schneider Electric’s supply chain.
Q: Do you provide a warranty on this part?
A: Yes. New original parts carry Schneider Electric’s standard warranty. New surplus parts carry a 90-day Konmask.com quality guarantee.
Q: Can you help me identify the correct replacement if my panel model is different?
A: Absolutely. Send your panel model number and a photo of the existing keypad to support@konmask.com and our engineers will advise.
