SIEMENS 6ES7288-3AQ02-0AA0 Analog Output Module | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7288-3AQ02-0AA0 is a 2-channel analog output expansion module designed for the S7-200 SMART PLC series. It delivers precise voltage/current signal outputs for process control applications. This page provides full technical specifications, compatible replacement models, selection guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Part Number: 6ES7288-3AQ02-0AA0
- Series: SIMATIC S7-200 SMART
- Module Type: Analog Output Expansion Module
- Output Channels: 2
- Output Signal: ±10 V (voltage) / 0–20 mA (current)
- Resolution: 12-bit
- Output Range (Voltage): ±10 V
- Output Range (Current): 0–20 mA
- Load Impedance (Voltage): ≥ 1 kΩ
- Load Impedance (Current): ≤ 500 Ω
- Supply Voltage: 24 V DC (via CPU bus)
- Power Consumption: Approx. 1.5 W
- Isolation: Optocoupler isolation between channels and bus
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Dimensions (W×H×D): 45 × 100 × 81 mm
- Weight: Approx. 250 g
- Protection Rating: IP20
- Certifications: CE, UL, cULus
- Connection Type: Removable screw terminal
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the 6ES7288-3AQ02-0AA0. Always verify electrical and mechanical compatibility before substitution.
- SIEMENS 6ES7288-3AQ02-0AA0 — Original OEM module (this listing)
- SIEMENS 6ES7232-4HB32-0XB0 — S7-1200 AQ2 analog output, different platform; requires wiring adaptation
- SIEMENS 6ES7235-0KD22-0XA8 — S7-200 (classic) analog I/O combo; legacy platform, not a direct drop-in
- Third-party S7-200 SMART-compatible AQ02 modules — Available from select OEM-grade suppliers; confirm firmware compatibility and terminal pinout before use
Note: Konmask.com recommends using genuine SIEMENS modules for safety-critical and continuous-process applications. Contact us for cross-reference verification.
Why Choose the Original Model
- Guaranteed Compatibility: Plug-and-play with all S7-200 SMART CPUs (ST20, ST30, ST40, ST60, SR20, SR30, SR40, SR60)
- Firmware Integrity: Fully supported by STEP 7-Micro/WIN SMART software without additional configuration
- Signal Accuracy: Factory-calibrated 12-bit DAC ensures ±0.5% full-scale accuracy
- Long-term Support: Covered under SIEMENS global warranty and spare-parts program
- Regulatory Compliance: CE/UL certified for use in industrial control panels
Typical Applications
- Variable-speed drive (VFD) speed reference signal output (0–10 V / 4–20 mA)
- Proportional valve and actuator control in hydraulic/pneumatic systems
- Temperature setpoint transmission to PID controllers
- Process signal conditioning in water treatment and HVAC systems
- Conveyor tension and position control in packaging machinery
- Analog setpoint output for industrial furnaces and kilns
System Compatibility
- Compatible CPUs: S7-200 SMART ST20 / ST30 / ST40 / ST60 / SR20 / SR30 / SR40 / SR60
- Programming Software: STEP 7-Micro/WIN SMART V2.3 and above
- Max Expansion Modules per CPU: Up to 6 expansion modules (subject to CPU model)
- Bus Interface: Proprietary S7-200 SMART expansion bus (not compatible with S7-200 classic or S7-300/400)
- Communication: Data exchange via CPU expansion bus; no additional fieldbus required
Selection Guide
Use the following criteria to confirm this module is the right choice for your application:
- Step 1 — Confirm PLC Platform: Verify your CPU is S7-200 SMART (not S7-200 classic or S7-1200)
- Step 2 — Count Output Channels: This module provides 2 analog output channels; if you need 4 channels, consider pairing two modules
- Step 3 — Verify Signal Type: Confirm whether your field device requires voltage (±10 V) or current (0–20 mA / 4–20 mA) input
- Step 4 — Check Load Impedance: Voltage output requires load ≥ 1 kΩ; current output requires load ≤ 500 Ω
- Step 5 — Count Total Expansion Slots: Ensure your CPU has an available expansion slot (max 6 modules per CPU)
- Step 6 — Confirm Power Budget: Add 1.5 W to your CPU power budget calculation
If you are unsure about any step, contact our technical team for a free pre-sales consultation.
Quality Assurance & Sourcing
- Origin: Genuine SIEMENS factory-new modules sourced through authorized distribution channels
- Inspection: Each unit undergoes incoming inspection including label verification, hologram check, and functional power-on test
- Traceability: Batch records and certificates of conformity available upon request
- Warranty: 12-month warranty against manufacturing defects from date of shipment
- Anti-counterfeit: We do not stock or sell refurbished, remarked, or grey-market components
How to Order
- Online: Add to cart directly on this page and proceed to checkout
- Email: Send your BOM or purchase order to [email protected]
- Phone/WhatsApp: +0086 19859288691
- Lead Time: In-stock orders ship within 1–3 business days; out-of-stock items subject to availability — contact us for ETA
- Payment: T/T bank transfer, PayPal, and other methods available — contact us for details
- Export: We support international shipping with commercial invoice, packing list, and COO documentation
Replacement & Compatibility FAQ
Q: Can I use the 6ES7288-3AQ02-0AA0 with an S7-200 (classic) CPU?
A: No. The S7-200 SMART expansion bus is not electrically or mechanically compatible with the classic S7-200 series. You need the 6ES7232-series modules for classic S7-200.
Q: Can I use this module with an S7-1200 or S7-300?
A: No. This module is exclusively for the S7-200 SMART platform. S7-1200 uses its own signal board and expansion module range (6ES7 2xx-xxxx-0XB0).
Q: Is 4–20 mA output supported?
A: The hardware supports 0–20 mA. A 4–20 mA range can be configured in software by scaling the output value in STEP 7-Micro/WIN SMART.
Q: Can I mix analog input and analog output modules on the same CPU?
A: Yes. S7-200 SMART supports mixed expansion configurations. Analog input modules (e.g., 6ES7288-3AE04-0AA0) and analog output modules can be used simultaneously within the 6-module limit.
Q: What is the difference between 6ES7288-3AQ02-0AA0 and 6ES7288-3AQ04-0AA0?
A: The AQ02 provides 2 analog output channels; the AQ04 provides 4 channels. Both are S7-200 SMART compatible and use the same signal types.
Q: Do you provide a datasheet or wiring diagram?
A: Yes. Contact [email protected] and we will provide the official SIEMENS datasheet and wiring reference.
