Yokogawa ASS9562DK-00 Analog Input Module | Replacement, Equivalent & Selection Guide
The Yokogawa ASS9562DK-00 is a high-precision analog input module designed for the STARDOM FCN/FCJ autonomous controller platform. It delivers reliable signal acquisition for process automation environments requiring accurate measurement of current and voltage signals. This page provides full technical specifications, compatible replacement options, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASS9562DK-00 |
| Brand | Yokogawa Electric Corporation |
| Series | STARDOM FCN / FCJ |
| Module Type | Analog Input (AI) |
| Input Channels | 8 channels (isolated) |
| Input Signal Range | 4–20 mA / 1–5 V DC |
| Resolution | 16-bit |
| Isolation | Channel-to-channel & channel-to-bus isolation |
| Communication Bus | FCN internal backplane bus |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -25°C to 70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Power Consumption | Supplied via FCN backplane |
| Weight | Approx. 920 g |
| Certifications | CE, UL (refer to Yokogawa datasheet for full listing) |
| Part Number | ASS9562DK-00 |
Compatible Replacement & Equivalent Models
When the ASS9562DK-00 is unavailable or end-of-life, the following models may serve as functional equivalents or drop-in replacements depending on your system configuration. Always verify compatibility with your FCN/FCJ firmware version before substitution.
| Model | Brand | Channels | Signal Type | Compatibility Notes |
|---|---|---|---|---|
| ASS9562DK-00 | Yokogawa | 8 CH | 4–20 mA / 1–5 V | Original OEM module — direct fit |
| ASS9562DK-01 | Yokogawa | 8 CH | 4–20 mA / 1–5 V | Revised hardware revision; verify firmware compatibility |
| ASS9562DK-10 | Yokogawa | 8 CH | 4–20 mA / 1–5 V | Extended temperature variant; check suffix meaning |
| ASS9562EK-00 | Yokogawa | 8 CH | Thermocouple / RTD | Different signal type — not a direct replacement |
| F3AD08-0N (YOKOGAWA FA-M3) | Yokogawa | 8 CH | 4–20 mA | Different platform — requires system redesign |
⚠ Note: Cross-platform substitution requires engineering validation. Contact Konmask.com for sourcing assistance.
Why Choose the Original Model
- Guaranteed Compatibility: Engineered specifically for the STARDOM FCN/FCJ backplane — no firmware patching or adapter required.
- Proven Reliability: Yokogawa’s industrial-grade components are rated for continuous 24/7 process operation.
- Regulatory Compliance: Maintains CE/UL certifications critical for regulated industries (oil & gas, pharmaceuticals, power generation).
- Vendor Support: Full Yokogawa technical support and documentation coverage.
- Long Service Life: Designed for 10+ year operational lifespan in harsh industrial environments.
Typical Applications
- Oil & gas process monitoring (flow, pressure, temperature signal acquisition)
- Chemical plant distributed control systems (DCS)
- Water treatment and utilities automation
- Power generation plant instrumentation
- Pharmaceutical batch process control
- Food & beverage production line monitoring
- Building management systems (BMS) with industrial I/O requirements
System Compatibility
The ASS9562DK-00 is designed exclusively for the Yokogawa STARDOM FCN/FCJ autonomous controller platform. Confirm the following before installation:
- FCN/FCJ chassis with available I/O slot
- STARDOM firmware version compatible with ASS9562DK-00 module descriptor
- Field wiring rated for 4–20 mA or 1–5 V DC signals
- Proper grounding and shielding per Yokogawa installation guidelines (IM 34M06H11-01E)
Selection Guide
Use the following criteria to confirm the ASS9562DK-00 is the right module for your application:
| Requirement | Recommended Action |
|---|---|
| Need 4–20 mA analog input on FCN/FCJ | ✅ ASS9562DK-00 is the correct choice |
| Need thermocouple or RTD input | Consider ASS9562EK-00 or ASS9562FK-00 |
| Need more than 8 channels | Add additional ASS9562DK-00 modules in available slots |
| Operating in high-vibration environment | Verify mounting and confirm with Yokogawa application engineering |
| Replacing a failed module | Match full part number including suffix (e.g., -00, -01) to ensure hardware revision match |
| Unsure of compatibility | Contact Konmask.com with your FCN chassis model and firmware version |
Quality Assurance & Sourcing
All Yokogawa ASS9562DK-00 modules sourced through Konmask.com are:
- ✅ Genuine OEM parts — no counterfeit or refurbished units without disclosure
- ✅ Inspected for physical integrity and label authenticity prior to shipment
- ✅ Shipped with original packaging where available
- ✅ Supported by our 12-month quality guarantee on new units
- ✅ Traceable to authorized distribution channels
We specialize in industrial automation components for B2B buyers in manufacturing, energy, and process industries. Fast global shipping available.
How to Order
- Confirm your part number: ASS9562DK-00
- Verify quantity and delivery timeline requirements
- Submit your inquiry via the product page or contact us directly
- Receive quotation within 1 business day
- Confirm order — we handle export documentation, customs HS code (8537.10), and logistics
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can I use ASS9562DK-00 in a non-Yokogawa system?
A: No. This module uses Yokogawa’s proprietary FCN backplane bus and is not compatible with third-party PLC or DCS platforms.
Q: Is the ASS9562DK-00 still in production?
A: Availability varies by region and production cycle. Contact Konmask.com to check current stock and lead times.
Q: What is the difference between ASS9562DK-00 and ASS9562DK-01?
A: The suffix typically denotes a hardware revision. Functional specifications are generally identical, but firmware compatibility should be verified with Yokogawa documentation.
Q: Can I mix ASS9562DK-00 with other AI modules in the same FCN chassis?
A: Yes, multiple analog input modules can coexist in the same chassis, subject to slot availability and power budget.
Q: Do you provide installation support?
A: Konmask.com provides sourcing and pre-sales technical guidance. For on-site installation, consult a certified Yokogawa system integrator.
