Industrial Communication Solution – ABB 3BHE057901R0101 PCD235 C101 | AC800M Series
Where This Product Is Used
The ABB 3BHE057901R0101 PCD235 C101 is a dedicated communication module engineered for the ABB AC800M Distributed Control System (DCS) platform. It is deployed across a wide range of process-critical environments where deterministic, high-integrity data exchange between controllers and field devices is non-negotiable:
- Oil & Gas: Upstream wellhead automation, midstream pipeline SCADA, and downstream refinery DCS networks
- Power Generation: Turbine control systems, boiler management, and grid-tie protection relay communication
- Pulp & Paper / Chemical: Continuous process control loops requiring redundant communication paths
- Water & Wastewater: Multi-site SCADA architectures with centralized AC800M controllers
- Pharmaceutical / Life Sciences: FDA 21 CFR Part 11-compliant batch control systems
- Mining & Metals: Smelter and concentrator automation with harsh-environment communication demands
Technical Specifications
| Part Number | 3BHE057901R0101 |
| Model | PCD235 C101 |
| Series | AC800M / PCD235 |
| Manufacturer | ABB |
| Module Type | Communication Module |
| Compatible Platform | ABB AC800M DCS Controller Family |
| Communication Protocol | ABB Industrial Ethernet / Proprietary AC800M Bus |
| Mounting | DIN-rail / AC800M backplane slot |
| Weight | 1,100 g (approx.) |
| Operating Temperature | 0 °C to +60 °C |
| Power Supply | Supplied via AC800M backplane |
| Firmware | Compatible with AC800M firmware v5.x and above |
Why Engineers Specify This Model
- Drop-in Replacement: Direct form-fit-function substitute for existing PCD235 C101 slots — no re-engineering of the control cabinet required.
- Deterministic Latency: Maintains cycle-time integrity in high-speed process loops where communication jitter causes process upsets.
- Redundancy Support: Supports hot-standby and redundant controller configurations critical for SIL-rated safety loops.
- Long Service Life: ABB AC800M platform has a documented multi-decade installed base; sourcing this module extends asset life without full DCS migration.
- Proven in Harsh Environments: Designed to IEC 61131-2 environmental standards for industrial EMC, vibration, and temperature ranges.
Complete System Bill of Materials
The PCD235 C101 is typically specified alongside the following AC800M ecosystem components:
- ABB PM866 / PM891 AC800M Controller CPU
- ABB TB807 / TB840 Termination Units
- ABB CI854 / CI857 Fieldbus Communication Interface Modules
- ABB SD802F / SD831 Power Supply Modules
- ABB MB510 / MB511 Modem / Bus Interface Modules
- ABB S800 I/O Modules (AI810, AO810, DI810, DO810)
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- IEC 61131-2 – Programmable Controllers: Equipment Requirements & Tests
- IEC 61508 / IEC 61511 – Functional Safety (SIL-compatible platform)
- CE Marking – EU Low Voltage and EMC Directives
- UL Listed (ABB AC800M platform)
- RoHS Compliant
Quality Assurance & Sourcing
- Authenticity: All units sourced from verified ABB authorized channels or certified surplus with full traceability documentation.
- Pre-shipment Testing: Each module undergoes functional power-on verification and visual inspection before dispatch.
- Packaging: Anti-static ESD packaging with foam insert protection; original ABB packaging where available.
- Warranty: 12-month replacement warranty against manufacturing defects.
- Lead Time: In-stock units ship within 1–3 business days; expedited options available.
How to Source This Part
- Confirm your AC800M firmware version and backplane slot compatibility.
- Verify quantity required — we support single-unit emergency replacements and multi-unit project orders.
- Submit your RFQ or purchase order to support@konmask.com or call +0086 19859288691.
- Receive pro-forma invoice with lead time confirmation within 24 hours.
- Worldwide shipping via DHL / FedEx / UPS with full export documentation.
Application-Specific FAQ
Q: Is the 3BHE057901R0101 compatible with AC800M firmware v6.x?
A: The PCD235 C101 is designed for AC800M platforms. Firmware compatibility should be verified against your specific controller CPU version. Contact us for confirmation.
Q: Can this module be used in a redundant controller configuration?
A: Yes. The AC800M platform supports redundant CPU and communication configurations; the PCD235 C101 is compatible with these architectures.
Q: Do you provide export documentation for international shipments?
A: Yes — we provide commercial invoice, packing list, certificate of origin, and HS code documentation (HS: 8537.10) for all international orders.
Q: What is the lead time for bulk orders (>5 units)?
A: Bulk orders are subject to stock availability. Contact us for a dedicated quote with confirmed lead time.
Q: Can you cross-reference this part to other ABB catalog numbers?
A: Yes. Our technical team can assist with cross-referencing PCD235 C101 to related ABB part numbers. Email support@konmask.com with your requirements.
