Bently Nevada 330101-00-16-10-02-05 – Eddy Current Proximity Probe | 3300 XL Series
Engineering Background
The Bently Nevada 3300 XL Proximity Transducer System is the global benchmark for continuous, non-contact shaft vibration and position measurement in rotating machinery. Developed and refined over decades of field deployment, the 3300 XL series is the preferred solution for turbines, compressors, pumps, and motors in oil & gas, power generation, and heavy process industries.
Product Positioning
The 330101-00-16-10-02-05 is a 5 mm eddy current proximity probe with a 16-inch (406 mm) integral armored cable, designed for direct integration into Bently Nevada 3300 XL monitoring systems. It delivers high-resolution, real-time radial vibration and axial position data critical for machinery protection and condition monitoring programs.
Complete Technical Specifications
| Part Number | 330101-00-16-10-02-05 |
| Brand | Bently Nevada (Baker Hughes) |
| Series | 3300 XL Proximity Transducer System |
| Probe Tip Diameter | 5 mm (0.197 in) |
| Cable Length | 16 inches (406 mm) integral armored cable |
| Thread Size | M10 × 1 (metric) |
| Connector | 10-32 coaxial (standard BN connector) |
| Measurement Type | Eddy current, non-contact |
| Linear Range | 0.25 – 2.25 mm (10 – 90 mil) |
| Sensitivity | 7.87 V/mm (200 mV/mil) nominal |
| Frequency Response | DC – 10,000 Hz (–3 dB) |
| Operating Temperature | –35°C to +177°C (–31°F to +351°F) |
| Target Material | AISI 4140 steel (standard); other alloys with calibration |
| Supply Voltage | –24 VDC (via Proximitor® driver) |
| Output | –2 to –18 VDC (proportional to gap) |
| Ingress Protection | IP67 |
| Weight | 220 g (approx.) |
| Compatible Driver | Bently Nevada 3300 XL 8mm Proximitor® (330180 series) |
| Certifications | CE, ATEX, IECEx (consult datasheet for zone ratings) |
Proven Application Environments
- Steam and gas turbine radial shaft vibration monitoring
- Centrifugal compressor rotor position and vibration measurement
- Pump and motor bearing journal orbit analysis
- Axial thrust position monitoring on critical rotating equipment
- Gearbox and expander shaft displacement measurement
- API 670-compliant machinery protection systems
Engineering Advantages
- Non-contact measurement: Zero mechanical wear; continuous operation without maintenance intervals
- Wide frequency response: DC to 10 kHz captures both slow-roll runout and high-frequency vibration events
- Armored integral cable: Protects signal integrity in high-vibration, high-temperature environments
- System-matched calibration: Factory-calibrated as a matched set with 3300 XL Proximitor® for ±1% accuracy
- API 670 compliant: Meets the industry standard for machinery protection instrumentation
- Proven field reliability: Deployed globally in refineries, LNG plants, and power stations
System Architecture & Signal Flow
The 330101-00-16-10-02-05 probe operates as part of a three-component transducer system:
- Proximity Probe (330101-00-16-10-02-05): Generates an eddy current field at the probe tip; gap changes modulate the oscillator circuit.
- Extension Cable (330130 series): Transmits the modulated signal from the probe to the Proximitor® driver. Total cable length (probe + extension) must equal the system-calibrated length (typically 5 m or 9 m).
- Proximitor® Driver (330180 series): Demodulates the signal and outputs a DC voltage proportional to the probe-to-target gap (–2 to –18 VDC). This output feeds directly into Bently Nevada 3500 or 3300 monitoring racks.
Note: All three components must be from the same calibrated system family to maintain specified accuracy.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified OEM surplus channels
- Each probe inspected for physical integrity, connector condition, and cable armor continuity prior to shipment
- Traceability documentation available upon request (batch records, COC)
- Konmask.com specializes in genuine Bently Nevada components — no counterfeit risk
- Lead time: In-stock units ship within 2–5 business days; inquire for volume orders
Procurement Process
- Confirm your system’s total cable length requirement (probe + extension = calibrated system length)
- Verify target material compatibility (AISI 4140 standard; other alloys require recalibration)
- Submit RFQ via support@konmask.com for volume pricing or expedited delivery
- Provide PO with delivery address; export documentation available for international shipments
- Payment: T/T, PayPal, credit card accepted
Technical FAQ
Q: Can this probe be used with a non-Bently Nevada monitoring system?
A: Yes, provided the receiving system accepts a –2 to –18 VDC analog output and the Proximitor® driver is powered correctly. However, system accuracy is only guaranteed when used with matched Bently Nevada components.
Q: What is the difference between the 330101 and 330105 probe series?
A: The 330101 series uses a 5 mm tip diameter; the 330105 series uses an 8 mm tip, offering a wider linear range (0.5–4.0 mm) and is preferred for larger shaft diameters.
Q: Is recalibration required after replacement?
A: If replacing with an identical part number from the same calibrated system family, recalibration is typically not required. Always verify with your site’s instrumentation engineer and applicable API 670 procedures.
Q: What is the maximum operating temperature?
A: The probe body is rated to +177°C. The integral cable insulation limits continuous exposure; consult the Bently Nevada datasheet (D350672) for derating curves at elevated temperatures.
Q: Do you provide ATEX-certified units?
A: Yes. The 330101 series is available with ATEX/IECEx certification for Zone 1/Zone 2 hazardous area installations. Confirm the suffix codes on your order for the correct certification variant.
