Vibration Monitoring Solution – Bently Nevada 330101-00-24-15-02-05 | 3300 XL Series
The Bently Nevada 330101-00-24-15-02-05 is a precision sensor extension cable engineered for the 3300 XL 8mm Proximity Probe System. Designed for continuous, high-reliability vibration and position monitoring in rotating machinery, this cable bridges the proximity probe and the Proximitor® sensor with minimal signal loss and maximum EMI resistance.
Where This Product Is Used
This extension cable is specified across a wide range of critical industrial applications where shaft vibration, axial position, and differential expansion monitoring are essential:
- Steam & Gas Turbines – Shaft radial vibration and thrust position monitoring on power generation turbines (50 MW–1000 MW class).
- Centrifugal Compressors – Continuous rotor orbit and bearing clearance monitoring in petrochemical and LNG plants.
- Pumps & Fans – Overhang rotor vibration detection in cooling water pumps and forced-draft fans.
- Gearboxes – High-speed pinion shaft monitoring in paper mills and steel rolling lines.
- Marine Propulsion Systems – Shaft alignment verification on diesel-electric vessels.
- Nuclear Power Plants – Safety-class vibration monitoring where cable routing distances exceed probe cable limits.
Technical Specifications
- Part Number: 330101-00-24-15-02-05
- Series: 3300 XL 8mm Proximity Probe System
- Cable Type: Sensor Extension Cable
- Compatible Probe: 3300 XL 8mm Proximity Probe (330101 series)
- Compatible Proximitor®: 3300 XL Proximitor® Sensor
- Cable Length: 24 ft (7.3 m) — per part number suffix
- Connector Type: Coaxial, factory-terminated
- Operating Temperature: –40°C to +85°C
- Impedance: 50 Ω nominal
- Jacket Material: Polyurethane (PUR), oil and abrasion resistant
- Weight: 120 g
- Country of Origin: USA
Why Engineers Specify This Model
- System-Matched Performance: Factory-calibrated to work within the 3300 XL probe/Proximitor® loop, ensuring the –24 VDC bias voltage and sensitivity (200 mV/mil) remain within API 670 tolerances.
- EMI/RFI Shielding: Double-shielded coaxial construction rejects interference from VFDs, switchgear, and high-current bus bars common in industrial environments.
- Plug-and-Play Replacement: Identical form, fit, and function to OEM cable — no recalibration required on the Proximitor® after swap.
- Harsh Environment Rated: PUR jacket withstands hydraulic oil, coolant, and cleaning solvents without jacket degradation.
- Reduced Downtime: Pre-terminated connectors eliminate field crimping errors that cause nuisance trips.
Complete System Bill of Materials
For a complete 3300 XL 8mm proximity probe measurement loop, the following components are required:
- Proximity Probe: 330101-00-24-10-02-05 (8mm, various lengths)
- Extension Cable: 330101-00-24-15-02-05 ← This Item
- Proximitor® Sensor: 330180-91-00 or 330180-X1-00
- Mounting Hardware: Probe holder, lock nut, and armored conduit per API 670 §5.3
- Signal Conditioner / Monitor: Bently Nevada 3500 Series rack (e.g., 3500/42M)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61511 – Functional Safety for SIS (compatible with SIL-rated loops)
- CE Marking – EMC Directive 2014/30/EU
- RoHS Compliant – Restriction of Hazardous Substances
- ISO 10816 / ISO 20816 – Mechanical vibration measurement on non-rotating parts
Quality Assurance & Sourcing
All Bently Nevada components supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes:
- Visual inspection for connector integrity and jacket damage
- Continuity and impedance verification prior to dispatch
- Anti-static packaging with humidity indicator card
- Traceability documentation available on request (batch/lot records)
We do not supply counterfeit, refurbished-as-new, or grey-market parts. Authenticity concerns? Request a certificate of conformance before purchase.
How to Source This Part
- In Stock: Ships within 1–3 business days from our warehouse.
- Lead Time (if out of stock): 2–4 weeks via authorized channel.
- Minimum Order Quantity: 1 piece.
- Bulk Pricing: Available for orders of 5+ units — contact us for a quote.
- Export: We ship globally. DDP/DAP Incoterms available. HS Code: 8544.42 (shielded cable assemblies).
- Contact: [email protected] | +0086 19859288691
Application-Specific FAQ
Q: Can I use this extension cable with the older 3300 (non-XL) probe system?
A: No. The 3300 XL system uses a different cable impedance and connector standard than the legacy 3300 series. Mixing components will result in out-of-tolerance sensitivity and potential false trips.
Q: What is the maximum total cable length (probe + extension) for the 3300 XL 8mm system?
A: The maximum combined cable length is 9 m (30 ft) per Bently Nevada specification. Exceeding this degrades the –24 VDC bias and shifts the linear range.
Q: Do I need to recalibrate the Proximitor® after replacing only the extension cable?
A: Not if you replace with the identical part number. The system is factory-calibrated as a matched set. If you change cable length or probe model, recalibration is required.
Q: Is this cable suitable for Zone 1 / Zone 2 hazardous area installations?
A: The cable itself is passive and does not require ATEX/IECEx certification. However, the Proximitor® sensor must be the appropriate Ex-rated variant for hazardous area use. Consult your area classification drawing before installation.
Q: Can Konmask supply the full 3300 XL probe loop kit (probe + extension + Proximitor®)?
A: Yes. Contact us with your loop configuration and we will provide a matched kit with a single line item quote.
