Bently Nevada 330104-16-23-10-02-00 Proximity Transducer System – 3300 XL 8mm Proximity Transducer Series
In critical rotating machinery — turbines, compressors, pumps, and generators — undetected shaft vibration or displacement can escalate from a minor anomaly to catastrophic mechanical failure within seconds. Without a precision proximity transducer system in place, maintenance teams are left blind to the early warning signs that separate a planned shutdown from an unplanned disaster. The Bently Nevada 330104-16-23-10-02-00 eliminates that blind spot, delivering continuous, non-contact measurement of radial shaft vibration, axial position, and differential expansion with the accuracy that mission-critical assets demand.
The 330104-16-23-10-02-00 belongs to Bently Nevada’s industry-defining 3300 XL 8mm Proximity Transducer Series — the global benchmark for eddy-current-based machinery protection. Within the 3300 XL family, this specific configuration (16-inch armored extension cable, 23-foot interconnect cable, 10-32 UNF reverse-mount tip, standard temperature range, no special options) is engineered for installations requiring a mid-length cable assembly with robust mechanical protection. Bently Nevada proximity systems are installed in over 80% of the world’s critical turbomachinery, making this series the de facto standard for OEM integrators, EPC contractors, and plant reliability engineers worldwide.
Technical Specifications
- Part Number: 330104-16-23-10-02-00
- Series: 3300 XL 8mm Proximity Transducer System
- Probe Tip Diameter: 8 mm
- Probe Thread: 10-32 UNF (Reverse Mount)
- Extension Cable Length: 16 inches (armored)
- Interconnect Cable Length: 23 feet
- Driver/Oscillator: 3300 XL Compatible Driver (sold separately or as system)
- Measurement Range: 0.25 mm to 2.25 mm (linear range)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Frequency Response: DC to 10,000 Hz
- Operating Temperature: -35°C to +177°C (probe); -35°C to +85°C (driver)
- Target Material: AISI 4140 steel (standard); other alloys with calibration
- Agency Approvals: CE, CSA, ATEX (consult datasheet for zone ratings)
- Connector: Standard BNC / integral cable
- Manufacturer: Bently Nevada (Baker Hughes)
Key Features & Benefits
- Non-Contact Measurement: Eddy-current technology eliminates mechanical wear, ensuring decades of maintenance-free operation in harsh industrial environments.
- High-Frequency Response (DC–10 kHz): Captures both slow-roll runout and high-frequency vibration events, providing complete machinery health data.
- Armored Extension Cable: The 16-inch armored extension provides superior protection against abrasion, chemical exposure, and mechanical damage in tight bearing housing installations.
- API 670 Compliant: Meets the American Petroleum Institute Standard 670 for machinery protection systems — mandatory for most oil & gas and petrochemical applications.
- Plug-and-Play with 3300 XL Monitors: Fully calibrated and matched to Bently Nevada 3300 XL monitor cards, eliminating field calibration time and reducing commissioning risk.
- Wide Temperature Range: Reliable performance from cryogenic LNG applications to high-temperature steam turbine environments.
- Long-Term Signal Stability: Precision-wound coil and temperature-compensated circuitry maintain calibration accuracy over the full service life.
Industry & Equipment Applications
- Oil & Gas: Centrifugal compressors, gas turbines, pipeline pumps, LNG expanders
- Power Generation: Steam turbines, gas turbines, hydro generators, turbo-generators
- Petrochemical & Refining: Reactor charge pumps, cracked gas compressors, process blowers
- Pulp & Paper: High-speed refiners, induced draft fans, boiler feed pumps
- Marine & Offshore: Propulsion turbines, offshore platform compressors
- General Industry: High-speed gearboxes, turbochargers, centrifugal chillers
System Integration & Compatible Parts
The 330104-16-23-10-02-00 is designed to operate as part of a complete Bently Nevada 3300 XL proximity transducer system. Compatible and commonly paired components include:
- Drivers/Oscillators: Bently Nevada 3300 XL 8mm Driver (e.g., 330180 series)
- Monitor Cards: Bently Nevada 3500/40M, 3500/42M, 3500/45, 3500/46M
- Rack Systems: Bently Nevada 3500 Machinery Protection System
- Interconnect Cables: 330130 series (standard), 330140 series (high-temperature)
- Mounting Hardware: Bently Nevada probe holders, lock nuts, and proximity probe guards
Contact our technical team at [email protected] for system configuration assistance and cross-reference support.
Our Quality Assurance Process
Every Bently Nevada 330104-16-23-10-02-00 unit sourced and supplied by Konmask.com undergoes a rigorous multi-stage verification process:
- Authenticity Verification: Serial number and date code cross-referenced against manufacturer records.
- Visual & Mechanical Inspection: Probe tip, cable jacket, connector, and labeling inspected for damage, tampering, or counterfeit indicators.
- Functional Pre-Check: Coil impedance and DC resistance measured against factory specifications.
- Original Packaging: Units shipped in original or equivalent ESD-safe packaging with full documentation.
- Traceability: Full supply chain documentation available upon request for regulated industries.
How to Order
- Submit your RFQ via the “Request a Quote” button on this page, or email [email protected] directly.
- Include your required quantity, delivery timeline, and destination country.
- Our team will respond within 24 business hours with pricing, lead time, and availability confirmation.
- Upon order confirmation, we issue a proforma invoice and arrange shipment via DHL, FedEx, or UPS with full tracking.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation & Control: We focus exclusively on PLC, DCS, and instrumentation components — not a generalist marketplace.
- ✅ Global Supply Network: Access to both new OEM stock and certified surplus inventory for obsolete or long-lead-time parts.
- ✅ Technical Expertise: Our team includes engineers with hands-on experience in Bently Nevada systems and turbomachinery protection.
- ✅ Fast Response: RFQ responses within 24 hours; emergency sourcing support available.
- ✅ Secure Shipping: Export-compliant packaging and documentation for international shipments.
- ✅ Trusted by Engineers Worldwide: Serving clients in oil & gas, power, petrochemical, and manufacturing across 30+ countries.
Frequently Asked Questions
- Q: Is the 330104-16-23-10-02-00 a complete system or just the probe?
- A: The 330104-16-23-10-02-00 is a complete proximity transducer system including the probe, armored extension cable, and interconnect cable. A compatible driver/oscillator (sold separately) is required to complete the measurement loop.
- Q: What is the difference between the 330104 and 330105 series?
- A: The 330104 series uses a standard 10-32 UNF reverse-mount thread configuration, while the 330105 series uses a 3/8-24 UNF thread. Selection depends on your probe holder and bearing housing design.
- Q: Can this transducer be used with non-Bently Nevada monitors?
- A: The 330104-16-23-10-02-00 outputs a standard eddy-current signal (nominally -18V DC bias, 200 mV/mil sensitivity) compatible with most third-party vibration monitors. However, full API 670 compliance and warranty are only guaranteed when used with Bently Nevada 3300 XL or 3500 series monitors.
- Q: What target materials are compatible?
- A: The standard calibration is for AISI 4140 steel. For other shaft materials (stainless steel, titanium, Inconel), a material-specific calibration factor must be applied. Contact us for calibration data sheets.
- Q: Do you provide export documentation for international orders?
- A: Yes. We provide commercial invoices, packing lists, certificates of origin, and can assist with export licensing requirements for regulated destinations.
