Rotating Machinery Vibration Monitoring Solution – Bently Nevada 330881-16-00-262-06-02 | 3300 XL Series
Where This Product Is Used
The Bently Nevada 330881-16-00-262-06-02 Proximity Transducer is an eddy-current non-contact displacement sensor engineered for continuous, real-time shaft vibration and position monitoring on critical rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines — radial vibration and axial position measurement on high-speed shafts in power generation plants
- Centrifugal Compressors — shaft orbit and eccentricity monitoring in petrochemical and LNG facilities
- Pumps & Fans — bearing journal displacement tracking in water treatment and HVAC systems
- Gearboxes — gear mesh frequency analysis and shaft runout detection
- Marine Propulsion Systems — continuous shaft monitoring in shipboard machinery
- Paper & Steel Mills — roll and spindle position feedback in heavy industrial drives
Technical Specifications
| Part Number | 330881-16-00-262-06-02 |
| Brand | Bently Nevada (Baker Hughes) |
| Series | 3300 XL 8mm Proximity Transducer System |
| Measurement Type | Non-contact eddy-current displacement |
| Thread Standard | Metric (M10 × 1.0) |
| Cable Length | 16 ft (≈ 5 m) integral cable |
| Tip Diameter | 8 mm |
| Linear Range | 0.25 – 2.25 mm (10 – 90 mil) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Frequency Response | DC – 10,000 Hz (–3 dB) |
| Supply Voltage | –24 VDC (nominal) |
| Temperature Range | –35 °C to +121 °C (–31 °F to +250 °F) |
| Target Material | AISI 4140 steel (standard); other alloys with calibration |
| Weight | 1,350 g (approx.) |
| Connector | Integral coaxial cable with BNC-compatible termination |
Why Engineers Specify This Model
- Proven 3300 XL Platform — the industry-standard eddy-current system trusted in over 100,000 machinery installations worldwide
- Metric Threading — direct drop-in replacement for metric-threaded probe bosses without adapter hardware
- Wide Temperature Tolerance — rated to +121 °C, suitable for hot-section turbine bearing pedestals
- High Frequency Response — DC to 10 kHz bandwidth captures sub-synchronous instabilities, blade-pass events, and gear mesh frequencies
- System Compatibility — fully interchangeable with Bently Nevada 3300 XL drivers (330180, 330130) and ADRE/System 1 condition monitoring software
- Integral Cable Design — eliminates field-assembled connectors, reducing installation error and signal noise
Complete System Bill of Materials
A complete 3300 XL proximity transducer system requires the following components:
- Probe (this item): 330881-16-00-262-06-02 — 8 mm Metric Proximity Transducer, 16 ft cable
- Extension Cable: 330130-080-00-00 (8 m) or 330130-045-00-00 (4.5 m) — matched coaxial extension
- Driver / Proximitor: 330180-X1-05 — 3300 XL 8 mm Proximitor Sensor (–24 VDC)
- Mounting Hardware: Metric probe holder, lock nut, and armored conduit fitting (site-supplied)
- Signal Conditioning: Bently Nevada 3500 Series rack or equivalent vibration monitor
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition) compliant probe system
- ISO 10816 / ISO 20816 — Mechanical vibration measurement guidelines
- CE Marking — EMC Directive 2014/30/EU
- RoHS Compliant — Restriction of Hazardous Substances
- ATEX / IECEx — consult factory for hazardous-area certified variants
Quality Assurance & Sourcing
Every unit offered by Konmask.com undergoes a structured verification process before dispatch:
- Visual inspection for housing integrity, cable jacket condition, and connector seating
- Functional bench test: output voltage linearity check across the specified linear range
- Traceability documentation: batch records and, where available, original factory test certificates
- Secure anti-static packaging with humidity indicator card for long-haul shipping
We source from authorized distributors, certified surplus channels, and direct OEM stock. All parts are guaranteed genuine Bently Nevada (Baker Hughes) components.
How to Source This Part
Ready to order or need a formal quotation? Contact our industrial automation team:
- Email: [email protected]
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders confirmed within 24 hours
- MOQ: 1 piece
- Payment: T/T, PayPal, credit card, and trade-term options available
- Export: Worldwide shipping with DHL, FedEx, and UPS express options
Application-Specific FAQ
Q: Is the 330881-16-00-262-06-02 compatible with my existing 3300 XL driver?
A: Yes. All 3300 XL 8 mm probes are system-matched to 3300 XL drivers. Verify the driver part number begins with 330180 for full compatibility.
Q: Can this probe measure non-ferrous targets such as aluminum or titanium?
A: The standard calibration is for AISI 4140 steel. Non-ferrous or exotic alloy targets require a target-specific calibration curve — contact us for recalibration services.
Q: What is the difference between the -262- and -05- connector codes in the part number?
A: The -262- designator indicates the probe body configuration and mounting thread (metric). The -06-02 suffix specifies the cable jacket and termination style. Always use the full part number when ordering to ensure exact replacement.
Q: Can I use this transducer in a hazardous (classified) area?
A: The standard 330881 series is not ATEX/IECEx certified. For Zone 1 or Zone 2 installations, specify the appropriate Bently Nevada intrinsically safe variant and consult your site safety engineer.
Q: What condition monitoring software is compatible?
A: The 330881-16-00-262-06-02 integrates natively with Bently Nevada System 1, ADRE 408 DSPi, and any third-party DCS/SCADA accepting a standard ±24 V proximity signal (4–20 mA with appropriate transmitter).
