Vibration Monitoring Solution – Bently Nevada 330904-00-15-05-02-00 | 3300 NSv Series
The Bently Nevada 330904-00-15-05-02-00 is a high-precision eddy-current proximity probe from the industry-leading 3300 NSv Series. Engineered for continuous, non-contact measurement of shaft radial vibration, axial position, and differential expansion, this probe is the preferred choice of rotating machinery engineers worldwide.
Where This Product Is Used
This proximity probe is deployed across critical rotating machinery applications in heavy industry:
- Steam & Gas Turbines — Continuous shaft radial vibration monitoring on HP/LP turbine stages to detect imbalance, misalignment, and rubs before catastrophic failure.
- Centrifugal Compressors — Axial position and radial vibration measurement on multi-stage compressors in petrochemical and LNG plants.
- Pumps & Fans — Bearing journal orbit analysis on large boiler feed pumps and induced draft fans in power generation facilities.
- Gearboxes — Gear mesh frequency monitoring and shaft displacement tracking in high-speed gearbox trains.
- Marine Propulsion Systems — Shaft monitoring on diesel-electric propulsion drives and reduction gearboxes.
- Paper & Steel Mills — Roll and drive shaft vibration surveillance in continuous process lines.
Technical Specifications
| Part Number | 330904-00-15-05-02-00 |
| Series | 3300 NSv (Non-Standard Voltage) |
| Probe Type | Eddy-Current Proximity Probe |
| Cable Length | 5 m (16.4 ft) integral armored cable |
| Extension Cable Length | 5 m |
| Tip Diameter | 8 mm (0.315 in) |
| Linear Range | 0.25 – 2.25 mm (10 – 90 mil) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Frequency Response | DC to 10,000 Hz (–3 dB) |
| Operating Temperature | –35°C to +177°C (–31°F to +351°F) |
| Target Material | AISI 4140 steel (standard); other alloys available |
| Connector | Integral coaxial, armored |
| Housing Material | 316 Stainless Steel |
| Ingress Protection | IP67 |
| Compatible Driver/Monitor | Bently Nevada 3300 XL / 3500 Series |
Why Engineers Specify This Model
- Non-Contact Measurement — Zero mechanical wear; suitable for continuous 24/7 operation in API 670-compliant machinery protection systems.
- High-Temperature Tolerance — Rated to +177°C, making it suitable for hot-section turbine bearing housings without derating.
- NSv Scale Factor Compatibility — The Non-Standard Voltage output (7.87 V/mm) integrates directly with 3300 XL and 3500 Series monitors without additional signal conditioning.
- Armored Cable Integrity — Stainless steel armor protects against mechanical damage in congested machinery spaces and high-vibration environments.
- Proven Field Reliability — The 3300 NSv platform has accumulated millions of operating hours across global power generation, oil & gas, and petrochemical installations.
Complete System Bill of Materials
A complete Bently Nevada 3300 NSv proximity measurement chain typically includes:
- Proximity Probe: 330904-00-15-05-02-00 (this item)
- Extension Cable: Bently Nevada 330130 Series (5 m or 9 m)
- Proximitor® Driver: Bently Nevada 330180 or 330185 Series
- Monitor Module: Bently Nevada 3500/40M or 3300 XL Monitor
- I/O Module: 3500/92 or 3500/94 for system integration
- Rack: Bently Nevada 3500 Rack with power supply
Contact Konmask for complete system quotations and compatibility verification.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition): Fully compliant for radial vibration, axial position, and speed measurement.
- ISO 10816 / ISO 20816 — Mechanical vibration evaluation of machines; probe output compatible with alarm setpoint configuration per standard.
- IEC 60079 — Hazardous area classifications; consult Bently Nevada for ATEX/IECEx certified variants.
- RoHS Compliant — Materials comply with EU Directive 2011/65/EU on restriction of hazardous substances.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Pre-shipment inspection includes visual examination, dimensional verification, and continuity/impedance testing.
- Packaging: Original OEM packaging where available; otherwise anti-static foam-lined export carton with desiccant.
- Shelf-life managed: units stored in climate-controlled warehouse (18–25°C, RH <60%).
- Certificate of Conformance (CoC) and test reports available upon request.
How to Source This Part
Konmask maintains stock of the Bently Nevada 330904-00-15-05-02-00 and related 3300 NSv components. To place an order or request a quotation:
- Online: Add to cart and proceed to checkout for standard orders.
- Email RFQ: support@konmask.com — include quantity, required delivery date, and ship-to country.
- Phone/WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock items ship within 2–3 business days; ex-stock orders within 7–14 business days.
- Export: We ship worldwide with full export documentation (commercial invoice, packing list, COO).
Application-Specific FAQ
Q: Is the 330904-00-15-05-02-00 compatible with the Bently Nevada 3500 Series monitors?
A: Yes. The 3300 NSv probe with 7.87 V/mm scale factor is directly compatible with 3500/40M and 3500/42M monitor modules configured for NSv input.
Q: What is the difference between the 330900 and 330904 series probes?
A: The 330904 series features an 8 mm tip diameter (vs. 5 mm for 330900), providing a wider linear range and improved performance on larger shaft diameters (>50 mm).
Q: Can this probe be used in hazardous (classified) areas?
A: The standard 330904-00-15-05-02-00 is not ATEX/IECEx certified. For Zone 1/Zone 2 or Division 1/Division 2 installations, consult Konmask for the appropriate certified variant.
Q: What target material is recommended for best linearity?
A: AISI 4140 steel is the standard calibration target. For stainless steel shafts (e.g., 316 SS), a target material correction factor must be applied — contact our technical team for calibration data.
Q: Do you offer calibration certificates?
A: Yes. Factory calibration certificates and third-party calibration reports are available upon request for an additional fee.
