BENTLY NEVADA 3500/93 135785-01 Display Unit | Replacement, Equivalent & Selection Guide
The Bently Nevada 3500/93 (P/N 135785-01) is a dedicated Display Unit for the 3500 Series Machinery Protection System. It provides a local operator interface for real-time vibration, position, and process variable monitoring directly at the rack. This page serves as a comprehensive selection guide covering technical specifications, compatible replacements, equivalent models, and application guidance for industrial automation engineers and procurement teams.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model / Part Number | 3500/93 — 135785-01 |
| Module Type | Display Unit |
| Series | 3500 Machinery Protection System |
| Display Type | Local operator display panel |
| Rack Compatibility | 3500 Series Rack (19-inch, 3U) |
| Communication | Internal rack bus |
| Power Supply | Supplied via rack backplane |
| Operating Temperature | 0 °C to +60 °C |
| Weight | Approx. 2,150 g |
| Certifications | CE, UL (refer to OEM datasheet for full listing) |
| Condition Available | New, Refurbished, Tested Surplus |
Note: Always verify specifications against the official Bently Nevada datasheet before final engineering decisions.
Compatible Replacement & Equivalent Models
When the 3500/93 135785-01 is unavailable or end-of-life, the following models may serve as functional replacements or equivalents depending on your rack configuration and firmware revision. Verify compatibility with your system integrator before substitution.
| Part Number | Description | Compatibility Notes |
|---|---|---|
| 135785-01 | 3500/93 Display Unit (this unit) | Direct match |
| 135785-02 | 3500/93 Display Unit Rev B | Functionally equivalent; confirm firmware |
| 3500/93-01-00 | Display Unit alternate ordering code | Same hardware, different catalog suffix |
| 3500/05-01-02-00-00-01 | 3500 Rack Interface Module | Complementary module; not a direct replacement |
Important: Substitution of display units in a live 3500 rack must be performed by qualified personnel following Bently Nevada installation procedures. Contact Konmask for pre-sales compatibility verification.
Why Choose the Original Model
- Guaranteed Interoperability: The 135785-01 is factory-validated for all 3500 Series racks without firmware modification.
- Regulatory Compliance: OEM-certified units maintain SIL and API 670 compliance records for audits.
- Long-Term Support: Original part numbers simplify spare-parts management and OEM service agreements.
- Proven Field Reliability: Deployed globally in oil & gas, power generation, and petrochemical facilities.
- Warranty Traceability: Sourcing original P/N preserves full traceability for insurance and maintenance records.
Typical Applications
- Rotating machinery protection in oil & gas upstream/downstream facilities
- Steam and gas turbine monitoring systems
- Compressor train vibration surveillance
- Pump and motor protection in petrochemical plants
- Power generation — combined cycle and nuclear auxiliary systems
- Marine propulsion and offshore platform machinery
System Compatibility
The 3500/93 135785-01 Display Unit is designed exclusively for use within the Bently Nevada 3500 Series Machinery Protection System rack architecture. It is not compatible with the 3300, 3701, or Orbit 60 Series without additional interface hardware.
- ✅ Compatible: 3500 Series Rack (all standard 19-inch chassis)
- ✅ Compatible: 3500/15 Power Supply Module
- ✅ Compatible: 3500/22M Transient Data Interface
- ⚠️ Conditional: 3500/92 Communication Gateway (verify firmware revision)
- ❌ Not Compatible: 3300 Series, Orbit 60 Series (different backplane architecture)
Selection Guide
Use the following decision framework to determine whether the 3500/93 135785-01 is the right module for your application:
- Confirm Rack Series: Is your existing rack a 3500 Series chassis? If yes, proceed. If no, contact Konmask for cross-series alternatives.
- Identify Display Requirement: Do you need local operator display at the rack face? The 3500/93 provides this; if remote HMI only is required, consider the 3500/92 Communication Gateway instead.
- Check Firmware Revision: Retrieve the rack firmware version from the System Manager software. Confirm the display unit firmware is compatible (Rev 3.xx or later recommended).
- Assess Condition Requirement: For critical SIL-rated loops, specify New OEM. For non-critical monitoring or budget-constrained projects, Tested Surplus may be acceptable.
- Quantity & Lead Time: For single-unit emergency replacement, Konmask typically ships within 1–3 business days from verified stock. For project quantities (>5 units), request a formal quotation.
Quality Assurance & Sourcing
- Source: Konmask.com sources 3500/93 135785-01 units from authorized distributors, OEM-certified repair centers, and verified surplus channels.
- Inspection: All units undergo visual inspection, functional power-on test, and communication bus verification prior to shipment.
- Documentation: Certificate of conformance, test report, and traceability documentation available upon request.
- Packaging: ESD-safe packaging with anti-static foam insert; double-boxed for international freight.
- Warranty: 12-month warranty on new units; 90-day warranty on tested surplus units (terms apply).
How to Order
- Add the 3500/93 135785-01 to your cart and proceed to checkout, or
- Email support@konmask.com with your PO or RFQ, including: part number, quantity, required condition (new/surplus), and delivery address.
- For urgent requirements, call +0086 19859288691 — our team responds within 2 business hours (GMT+8).
- For project or bulk orders (>5 units), request a formal quotation for volume pricing.
Replacement & Compatibility FAQ
Q: Can the 3500/93 135785-01 replace the 135785-02?
A: In most cases yes — both are 3500/93 Display Units with minor revision differences. Confirm firmware compatibility with your rack’s System Manager software before hot-swapping.
Q: Is this module compatible with the Bently Nevada System 1 software?
A: The 3500/93 Display Unit provides local display only. System 1 connectivity is handled via the 3500/92 Communication Gateway, not the display unit.
Q: Can I use a refurbished unit in a SIL-rated application?
A: This depends on your site’s functional safety management plan. Consult your safety engineer. Konmask can provide full test documentation to support your assessment.
Q: What is the lead time for new OEM units?
A: Typically 1–3 business days for in-stock units. Extended lead times may apply for factory-new OEM orders. Contact us for current availability.
Q: Do you offer exchange / core return programs?
A: Yes. Contact support@konmask.com to discuss exchange pricing if you have a faulty unit to return as core.
