Honeywell 2MLQ-TR4B – 4-Channel Transistor Output Module | TDC 3000 DCS Platform
Engineering Background: The Honeywell 2MLQ-TR4B is a digital transistor output module designed for the Honeywell TDC 3000 Distributed Control System (DCS). It provides reliable NPN open-collector transistor switching outputs for discrete field device control in process automation environments. This module is a critical interface component between the DCS controller and field actuators, solenoids, and relay coils in continuous process industries.
Product Positioning: Targeted at procurement engineers and MRO buyers maintaining legacy TDC 3000 installations in refining, petrochemical, power generation, and chemical processing plants. The 2MLQ-TR4B is a direct OEM replacement module, ensuring full backward compatibility with existing I/O racks and system configurations without requiring software reconfiguration.
Complete Technical Specifications
- Part Number: 2MLQ-TR4B
- Manufacturer: Honeywell Process Solutions
- Module Type: Digital Transistor Output (DO)
- Output Channels: 4 channels
- Output Type: NPN open-collector transistor
- Output Voltage: 24 VDC nominal
- Output Current: Per channel (refer to TDC 3000 I/O documentation)
- Logic Level: TTL-compatible discrete output
- Platform Compatibility: Honeywell TDC 3000 DCS I/O subsystem
- Form Factor: Plug-in card module for TDC 3000 I/O rack
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Weight: Approx. 100 g
- Compliance: Designed to Honeywell TDC 3000 system standards
- Country of Origin: USA
Proven Application Environments
- Oil & gas refining — solenoid valve control and discrete actuator switching
- Petrochemical plants — motor starter and relay coil drive circuits
- Power generation — turbine auxiliary control and BOP discrete outputs
- Chemical processing — batch reactor sequencing and interlock output signals
- Pulp & paper — process line discrete control and safety shutdown outputs
- Pharmaceutical manufacturing — validated DCS output for GMP-compliant processes
Engineering Advantages
- Direct OEM Replacement: Plug-and-play compatibility with TDC 3000 I/O racks — no firmware changes or reconfiguration required
- NPN Open-Collector Output: Flexible field wiring for sinking-type loads; compatible with standard industrial relay and solenoid coils
- 4-Channel Density: Maximizes rack utilization and minimizes spare parts inventory per I/O slot
- Proven Field Reliability: Honeywell TDC 3000 platform modules are engineered for 24/7 continuous process operation with high MTBF ratings
- Backward Compatible: Supports existing TDC 3000 system configurations without engineering rework
- MRO-Ready: Stocked as a critical spare to minimize unplanned downtime risk
System Architecture & Signal Flow
The 2MLQ-TR4B resides in the Honeywell TDC 3000 I/O subsystem rack, receiving discrete output commands from the High-Performance Process Manager (HPM) or Basic Process Manager (BPM) controller via the Local Control Network (LCN) or Universal Control Network (UCN). Each of the 4 output channels drives an NPN transistor switch that sinks current through the connected field device (solenoid, relay coil, or indicator lamp). The module interfaces directly with the I/O rack backplane, drawing logic power from the rack power supply while switching field-side 24 VDC loads. Field wiring connects via the module’s front-face terminal connector to the marshalling cabinet or field junction box.
Sourcing & Quality Verification
- Source: Konmask.com sources 2MLQ-TR4B modules from verified industrial surplus channels, authorized distributors, and decommissioned plant inventories with documented service history
- Inspection: Each unit undergoes visual inspection for physical integrity, connector condition, and label verification prior to listing
- Authenticity: All modules carry original Honeywell part markings and serial identification; no counterfeit or remarked parts
- Condition: Units are listed as tested-good refurbished or new surplus; condition is specified per order confirmation
- Warranty: 90-day functional warranty against DOA; extended warranty available upon request
Procurement Process
- Confirm part number 2MLQ-TR4B matches your TDC 3000 I/O rack slot requirement
- Submit RFQ or place order directly via Konmask.com product page
- Receive order confirmation with unit condition, serial number, and lead time within 1 business day
- Secure export documentation and commercial invoice provided for international shipments
- DHL / FedEx international express shipping available; EXW Xiamen or CIF terms negotiable for bulk orders
- Contact support@konmask.com for volume pricing, consignment stock programs, or technical pre-sales support
Technical FAQ
Q: Is the 2MLQ-TR4B compatible with both HPM and BPM controllers in TDC 3000?
A: Yes. The module is a standard TDC 3000 I/O rack card and is compatible with all TDC 3000 process manager variants that support the standard I/O subsystem.
Q: Can this module be used in a Safety Manager (SM) or FSC system?
A: No. The 2MLQ-TR4B is a standard (non-SIL-rated) output module for the TDC 3000 process control system. It is not certified for use in Honeywell Safety Manager or FSC safety instrumented systems.
Q: What is the output load capacity per channel?
A: Refer to the Honeywell TDC 3000 I/O Module Specification document for the 2MLQ series. Contact Konmask technical support for assistance locating the applicable datasheet.
Q: Do you provide a test report or functional verification certificate?
A: Yes, upon request. Functional test reports are available for refurbished units. Please specify this requirement at time of order.
Q: What are the shipping lead times?
A: In-stock units ship within 2–3 business days. International express delivery (DHL/FedEx) typically 3–7 business days to most destinations.
