Schneider Electric 170AMM09000 Analog/Discrete I/O Base Module | Replacement, Equivalent & Selection Guide
The Schneider Electric 170AMM09000 is a combined Analog and Discrete Input/Output Base module designed for the Modicon Momentum distributed I/O platform. It provides flexible signal handling for process control, machine automation, and industrial monitoring applications. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing the 170AMM09000 or its equivalents.
Technical Specifications
- Part Number: 170AMM09000
- Brand: Schneider Electric (Modicon)
- Series: Modicon Momentum
- Module Type: Analog / Discrete Combined I/O Base
- Analog Inputs: 4 channels (0–10 V / 4–20 mA selectable)
- Analog Outputs: 2 channels (0–10 V / 4–20 mA selectable)
- Discrete I/O: Integrated discrete I/O capability
- Resolution: 12-bit analog conversion
- Communication: Compatible with Momentum adapter heads (Modbus, Ethernet, Profibus, etc.)
- Power Supply: 24 VDC (via adapter head)
- Operating Temperature: 0°C to 60°C
- Dimensions: Standard Momentum base form factor
- Weight: Approx. 1,100 g
- Certifications: CE, UL, cUL
- Country of Origin: France / EU
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents for the 170AMM09000. Always verify signal type, channel count, and adapter head compatibility before substitution.
- 170ANR12090 – Momentum Analog Input Base (4 AI), partial replacement for analog input channels
- 170ANO12000 – Momentum Analog Output Base (2 AO), partial replacement for analog output channels
- 170ADM35010 – Momentum Discrete I/O Base, for discrete-only replacement scenarios
- BMXAMI0410 – Modicon M340 Analog Input Module (requires platform migration)
- BMXAMO0210 – Modicon M340 Analog Output Module (requires platform migration)
- Third-party equivalents: Contact Konmask for cross-brand compatibility assessment (Siemens, Mitsubishi, ABB analog I/O modules)
Note: Direct drop-in replacement requires matching the Momentum adapter head interface. Platform migration to M340 or M580 requires engineering review.
Why Choose the Original 170AMM09000
- Proven reliability in Modicon Momentum distributed I/O architectures
- Combined analog + discrete I/O in a single base reduces panel space and wiring complexity
- Flexible signal configuration supports both voltage and current loop signals
- Seamless integration with all Momentum communication adapter heads
- Long field service history with extensive installed base in process and factory automation
- Genuine OEM quality ensures full firmware and diagnostic compatibility
Typical Applications
- Process control: temperature, pressure, flow, and level monitoring via 4–20 mA transmitters
- Machine automation: servo drive reference signals and feedback acquisition
- Water & wastewater treatment plant distributed I/O nodes
- Oil & gas field instrumentation panels
- Building management systems (BMS) with mixed analog/discrete field devices
- Conveyor and material handling systems requiring mixed signal types
System Compatibility
- Platform: Modicon Momentum Distributed I/O
- Compatible Adapter Heads: 170ENT11001 (Ethernet), 170PNT11000 (Profibus DP), 170INT11000 (Interbus), 170DNT11000 (DeviceNet), 170MCI01600 (Modbus)
- Programming Software: Unity Pro, Concept, ProWORX
- Compatible PLCs: Modicon Quantum, Modicon Premium (via network), standalone Momentum CPU heads
- Not compatible with: M340, M580, or Advantys STB without adapter/gateway
Selection Guide
Use the following criteria to confirm the 170AMM09000 is the correct module for your application:
- Step 1 – Signal type: Confirm you require both analog (AI/AO) and discrete I/O on a single base. If analog-only, consider 170ANR12090 or 170ANO12000.
- Step 2 – Channel count: Verify 4 AI + 2 AO + discrete channels meet your I/O budget.
- Step 3 – Signal range: Confirm field devices output 0–10 V or 4–20 mA; thermocouple/RTD inputs require a different module (e.g., 170ANR12090 variants).
- Step 4 – Adapter head: Match your network protocol (Modbus, Ethernet, Profibus, etc.) to the correct Momentum adapter head.
- Step 5 – Platform: If migrating from Momentum to M340/M580, contact Konmask for a full migration BOM and engineering support.
Quality Assurance & Sourcing
- All units sourced through authorized distribution channels or verified surplus with full traceability
- Pre-shipment inspection: visual, label verification, and functional power-on test where applicable
- Anti-counterfeit measures: hologram label check, firmware version verification
- Packaging: original OEM packaging preferred; ESD-safe packaging for all shipments
- Warranty: 12-month warranty against manufacturing defects
- Certificates of conformance (CoC) and test reports available on request
How to Order
- Part Number: 170AMM09000
- Quantity: Single unit or bulk orders accepted
- Lead Time: In-stock items ship within 1–3 business days; contact us for large quantity lead times
- Payment: T/T, PayPal, credit card, and trade terms available for qualified accounts
- Shipping: DHL, FedEx, UPS worldwide; sea freight available for bulk orders
- Request a Quote: Email [email protected] or call +0086 19859288691
- Online Order: Add to cart directly on Konmask.com
Replacement & Compatibility FAQ
Q: Can I replace 170AMM09000 with a standard M340 analog module?
A: Not directly. The Momentum base uses a proprietary backplane interface. Migration to M340 requires replacing the entire I/O node including adapter head and rewiring.
Q: Is 170AMM09000 still in production?
A: Schneider Electric has transitioned newer projects to M340/M580 platforms. The 170AMM09000 is available as a spare/replacement part through authorized distributors and surplus channels.
Q: What is the difference between 170AMM09000 and 170ANR12090?
A: The 170AMM09000 combines analog and discrete I/O; the 170ANR12090 is analog input only with no discrete capability.
Q: Can Konmask provide a tested unit?
A: Yes. Functional testing is available on request. Contact us for details and pricing.
Q: Do you offer volume discounts?
A: Yes, volume pricing is available for orders of 5+ units. Request a formal quote via email.
