Industrial Drive Control Solution – Schneider Electric PN072545P1 | Altivar Series
Where This Product Is Used
The Schneider Electric PN072545P1 printed circuit board is a core control component deployed across demanding industrial environments. Typical application scenarios include:
- Variable Frequency Drive (VFD) Repair & Maintenance — Replacement control PCB for Altivar series drives experiencing logic faults, communication failures, or power board damage in manufacturing lines.
- Conveyor & Material Handling Systems — Restoring motor speed control in logistics centers, packaging plants, and automated warehouses.
- HVAC & Building Automation — Reinstating drive functionality in fan and pump control panels for commercial buildings and industrial facilities.
- Water & Wastewater Treatment Plants — Maintaining continuous pump operation in critical infrastructure where drive downtime is unacceptable.
- Oil & Gas / Petrochemical Facilities — Sustaining compressor and agitator drive control in hazardous-area adjacent panels.
- Food & Beverage Processing — Keeping mixer, conveyor, and filling-line drives operational with minimal production interruption.
Technical Specifications
- Part Number: PN072545P1
- Manufacturer: Schneider Electric
- Series: Altivar (ATV) Drive Series
- Component Type: Printed Circuit Board (Control Board / PCB Assembly)
- Weight: 380 g
- Board Function: Drive logic control, signal processing, and I/O interface
- Compatibility: Altivar series variable speed drives (confirm exact drive model before ordering)
- Condition: New / Surplus New (specify at inquiry)
- Country of Origin: France / Global Manufacturing
Why Engineers Specify This Model
- OEM Exact-Match Replacement — Direct drop-in for failed or damaged control boards; no firmware re-flashing required in most configurations.
- Proven Reliability — Schneider Electric’s Altivar platform is trusted in millions of drive installations worldwide; the PN072545P1 meets the same design standards.
- Reduced Downtime — Stocking this board as a critical spare eliminates multi-week lead times from OEM channels during emergency breakdowns.
- Full Signal Integrity — Designed to maintain precise PWM signal generation and encoder feedback processing essential for closed-loop motor control.
- Long Service Life — Industrial-grade PCB construction with conformal coating options for humid or dusty environments.
Complete System Bill of Materials
When replacing the PN072545P1, engineers typically also evaluate the following complementary components:
- Altivar Drive Power Board / IGBT Module
- Altivar Drive Keypad / HMI Display Panel
- 24 VDC Control Power Supply Module
- Drive Input/Output Terminal Block Assembly
- EMC Line Filter (input side)
- Dynamic Braking Resistor (if applicable)
Contact support@konmask.com to source a complete BOM package.
Compliance & Industry Standards
- CE Marked — Compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed (drive-level certification)
- RoHS Compliant — Restriction of Hazardous Substances
- ISO 9001 Manufacturing Quality System
- IEC 61800 series — Adjustable speed electrical power drive systems
Quality Assurance & Sourcing
At Konmask.com, every Schneider Electric component is sourced through verified industrial distribution channels. Our quality process includes:
- Visual inspection and packaging integrity check upon receipt
- Cross-reference verification against Schneider Electric part databases
- Anti-static packaging and climate-controlled storage
- Traceability documentation available upon request (date codes, lot numbers)
- 30-day return policy for verified non-conforming parts
How to Source This Part
- Add to Cart — Place your order directly on Konmask.com for in-stock units.
- Request a Quote — For bulk quantities (>5 units) or urgent requirements, email support@konmask.com for priority pricing.
- Confirm Compatibility — Provide your Altivar drive model number and nameplate data so our engineers can verify exact fit before shipment.
- Global Shipping — We ship worldwide via DHL, FedEx, and UPS Express. Export documentation and commercial invoices provided.
Application-Specific FAQ
Q: Is the PN072545P1 compatible with all Altivar drive models?
A: The PN072545P1 is designed for specific Altivar drive variants. Please share your drive’s full model reference (found on the nameplate) with our team to confirm compatibility before ordering.
Q: Can this board be used as a direct replacement without reprogramming?
A: In most cases, yes — the board retains drive parameters stored in the keypad or external memory card. However, we recommend verifying firmware version compatibility with your site engineer.
Q: Do you offer exchange / repair services for faulty PN072545P1 boards?
A: Yes. Contact us at support@konmask.com to discuss board exchange or third-party repair options to reduce your replacement cost.
Q: What is the lead time for out-of-stock units?
A: Typical sourcing lead time is 3–10 business days for surplus stock and 4–8 weeks for new OEM orders. Contact us for real-time availability.
Q: Is export to my country permitted?
A: Schneider Electric components are generally exportable. We handle all export documentation. Contact us if your country has specific import requirements.
