Bently Nevada 330903-00-05-05-01-00 – Non-Contact Shaft Vibration Transducer | 3300 XL NSv Platform
Engineering Background: The Bently Nevada 3300 XL NSv (Non-Standard Voltage) Proximity Transducer System is engineered for continuous, non-contact measurement of shaft radial vibration, axial position, and differential expansion in critical rotating machinery. Developed under GE’s Bently Nevada machinery protection portfolio, the 3300 XL series represents the industry benchmark for turbomachinery condition monitoring in power generation, oil & gas, and petrochemical facilities.
Product Positioning: Part number 330903-00-05-05-01-00 is a complete NSv transducer system configured for 5-meter extension cable, 5-meter armored driver cable, and standard 8 mm probe tip — optimized for installations requiring extended cable runs in high-temperature or high-vibration environments. This unit integrates directly with Bently Nevada 3300 series monitors and System 1 software for real-time asset health analytics.
Complete Technical Specifications
- Part Number: 330903-00-05-05-01-00
- Series / Platform: Bently Nevada 3300 XL NSv
- Measurement Type: Eddy-current non-contact proximity
- Probe Tip Diameter: 8 mm
- Extension Cable Length: 5 m (armored)
- Driver Cable Length: 5 m
- Output Voltage (NSv): Non-Standard Voltage output, compatible with 3300 XL monitors
- Frequency Range: DC – 10,000 Hz
- Operating Temperature: –35 °C to +177 °C (probe); –35 °C to +85 °C (driver)
- Gap Range: 0.25 mm – 2.54 mm (linear range)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Target Material: AISI 4140 steel or equivalent ferromagnetic alloy
- Ingress Protection: IP67 (probe assembly)
- Approvals: CE, ATEX, IECEx (intrinsically safe configurations available)
- Connector Type: Standard BNC / MIL-spec per Bently Nevada wiring standard
- Weight: ~60 g (probe + cable assembly)
- Country of Origin: United States
Proven Application Environments
- Steam and gas turbines (power generation, combined-cycle plants)
- Centrifugal and axial compressors (upstream/downstream oil & gas)
- Boiler feed pumps and large motor-driven equipment
- Gearboxes and expanders in petrochemical processes
- Hydro turbines and pump-storage facilities
- Marine propulsion shafting systems
Engineering Advantages
- NSv Output Compatibility: Designed exclusively for 3300 XL monitor inputs — eliminates signal conditioning errors common with third-party substitutes.
- Extended Cable Configuration: 5 m + 5 m cable assembly supports installations where the driver must be located outside high-temperature zones (>85 °C).
- High EMI Immunity: Armored cable construction rejects electromagnetic interference from VFDs, switchgear, and high-current bus bars.
- Plug-and-Play Integration: Direct replacement for existing 330903 series probes — no recalibration of monitor required when replacing like-for-like.
- Long Service Life: Solid-state design with no moving parts; MTBF >100,000 hours in rated conditions.
System Architecture & Signal Flow
The 330903-00-05-05-01-00 operates as a three-component eddy-current system:
- Probe (8 mm tip): Generates a high-frequency electromagnetic field; gap changes modulate the field impedance.
- Extension Cable (5 m armored): Transmits the modulated signal from the probe to the driver with minimal loss.
- Driver / Oscillator-Demodulator (5 m cable): Converts the impedance modulation into a DC voltage output proportional to gap distance, feeding the 3300 XL monitor input card.
The monitor processes the DC signal against configured alert/danger setpoints and transmits data to Bently Nevada System 1 or third-party DCS/SCADA via 4–20 mA or Modbus RTU.
Sourcing & Quality Verification
- All units sourced from authorized distributors or verified OEM surplus channels.
- Each unit undergoes incoming inspection: visual, dimensional, and functional gap-output linearity check.
- Serialization and firmware/hardware revision verified against Bently Nevada product change notices (PCNs).
- Calibration certificates and test reports available upon request for critical-service applications.
- Packaging inspected for moisture ingress, connector damage, and cable jacket integrity prior to dispatch.
Procurement Process
- Submit your RFQ via support@konmask.com or WhatsApp +0086 19859288691.
- Receive a formal quotation with lead time, unit price, and shipping options within 24 hours.
- Confirm purchase order — payment via T/T, PayPal, or credit card accepted.
- Unit ships within 1–3 business days; tracking number provided upon dispatch.
- Post-delivery technical support available for installation and commissioning queries.
Technical FAQ
Q: Is the 330903-00-05-05-01-00 compatible with the 3300/16 monitor?
A: Yes. The NSv output is compatible with all 3300 XL series monitor input cards, including the 3300/16 and 3300/55 proximity monitor modules.
Q: Can this probe measure axial position as well as radial vibration?
A: Yes. With appropriate mounting (thrust collar target), the system measures both radial vibration and axial shaft position within the linear gap range.
Q: What is the maximum ambient temperature at the driver location?
A: The driver is rated to 85 °C continuous. For higher ambient installations, use the high-temperature driver variant (330180 series).
Q: Do you provide ATEX-certified units?
A: ATEX/IECEx certified configurations are available — please specify zone classification in your RFQ.
Q: What is the lead time for this part number?
A: Typically 1–5 business days from stock. For large quantities or urgent requirements, contact us directly for availability confirmation.
