Vibration Monitoring Solution – Bently Nevada 3500/05-01-01-00-00-01 | 3500 Series System Rack
Where This Product Is Used
The Bently Nevada 3500/05-01-01-00-00-01 System Rack is the structural and electrical backbone of the 3500 Series machinery protection system. It is deployed across the most demanding continuous-process industries where unplanned downtime carries catastrophic operational and financial consequences:
- Oil & Gas: Compressor trains, gas turbines, and centrifugal pumps on offshore platforms and onshore processing facilities
- Power Generation: Steam turbine-generator sets, hydro turbines, and combined-cycle plant rotating equipment
- Petrochemical & Refining: Reactor charge pumps, cracked-gas compressors, and critical agitators
- LNG Terminals: Main refrigerant compressors and boil-off gas handling trains
- Pulp & Paper / Mining: Large induced-draft fans, ball mills, and kiln drive systems
- Marine & Offshore: Propulsion turbines and FPSO rotating machinery
Wherever API 670 compliance is mandated and continuous vibration, position, and speed monitoring is required, the 3500 rack is the industry reference platform.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 3500/05-01-01-00-00-01 |
| Series | Bently Nevada 3500 |
| Description | System Rack (Main Chassis) |
| Rack Slots | Up to 14 module slots (I/O + power) |
| Power Supply Input | 85–264 V AC / 88–300 V DC (redundant PSU capable) |
| Communication Backplane | Integrated Rack Interface Module (RIM) bus |
| Supported Modules | 3500/20, 3500/22, 3500/25, 3500/40, 3500/42, 3500/45, 3500/50, 3500/60, 3500/61, 3500/64, 3500/72, 3500/77, 3500/92, 3500/93 |
| Relay Output | Via dedicated relay modules (3500/32, 3500/33) |
| Operating Temperature | 0 °C to +65 °C |
| Storage Temperature | −40 °C to +85 °C |
| Humidity | 5–95% RH, non-condensing |
| Enclosure Rating | Panel-mount; suitable for NEMA 4 / IP54 enclosures |
| Dimensions (H × W × D) | Approx. 266 mm × 483 mm × 305 mm (19″ rack-mount) |
| Weight | ~300 g (chassis only, without modules) |
| Certifications | CE, cULus, FM, ATEX (zone-dependent configuration) |
Why Engineers Specify This Model
- API 670 Native Compliance: Designed from the ground up to meet the 5th Edition API 670 standard for machinery protection systems — no additional engineering workarounds required.
- Modular Architecture: A single rack accommodates vibration, position, speed, temperature, and process variable monitoring modules, eliminating multi-vendor integration complexity.
- Redundant Power Architecture: Dual power supply slots allow hot-swap redundancy, ensuring the protection system remains live during PSU maintenance or failure.
- Proven Field Reliability: The 3500 platform has accumulated decades of runtime in tier-1 refineries and power plants globally — a track record that reduces project risk for EPC contractors and end-users alike.
- Seamless System 1 Integration: Native communication with GE/Baker Hughes System 1 Evolution software enables real-time condition monitoring, trending, and predictive maintenance analytics.
- Backward Compatibility: Accepts legacy 3500 series modules, protecting prior capital investment during plant upgrades or expansions.
Complete System Bill of Materials
A fully functional 3500 protection system built around this rack typically includes:
- 3500/05 — System Rack (this unit)
- 3500/15 — Power Supply Module (×1 or ×2 for redundancy)
- 3500/20 — Rack Interface Module (RIM) for host communications
- 3500/22 — Transient Data Interface (TDI)
- 3500/40M or 3500/42M — Proximitor / Seismic Monitor (vibration channels)
- 3500/45 — Position Monitor (thrust, differential expansion)
- 3500/50 — Tachometer Module (speed / phase reference)
- 3500/60 — Temperature Monitor (thermocouple / RTD)
- 3500/32 or 3500/33 — Relay Output Module
- 3500/92 or 3500/93 — TMR / Voting Logic Module (for SIL-rated applications)
Contact Konmask for complete BOM configuration support and cross-reference assistance.
Compliance & Industry Standards
- API 670 (5th Edition) — Machinery Protection Systems
- IEC 61511 / IEC 61508 — Functional Safety (SIL-capable configurations)
- ISO 10816 / ISO 20816 — Mechanical Vibration Evaluation
- ATEX Directive 2014/34/EU — Explosive Atmospheres (zone-specific module selection required)
- IECEx — International Explosive Atmospheres Certification
- CE Marking — EU Machinery Directive
- cULus Listed — North American Safety
- FM Approved — Factory Mutual Industrial
Quality Assurance & Sourcing
Konmask.com sources the Bently Nevada 3500/05-01-01-00-00-01 through verified industrial distribution channels with full traceability documentation. Every unit dispatched from our inventory undergoes the following quality process:
- Visual & Physical Inspection: Connector integrity, PCB condition, label legibility, and housing checks against OEM reference standards
- Serialization Verification: Serial number cross-referenced against Bently Nevada / Baker Hughes product genealogy records where available
- Functional Pre-check: Backplane continuity and slot integrity verified prior to shipment
- Packaging: ESD-safe anti-static bags, foam-lined cartons, and humidity indicator cards for long-haul freight
- Documentation Package: Certificate of conformance, inspection report, and commercial invoice with HS code declaration included
How to Source This Part
The 3500/05-01-01-00-00-01 is a controlled-availability industrial component. Konmask maintains stock of both new-surplus and reconditioned units to support urgent plant requirements and long-lead procurement programs.
- Submit an RFQ: Email support@konmask.com with your required quantity, delivery timeline, and destination port.
- Receive a Quotation: Our technical sales team responds within 1 business day with pricing, lead time, and available condition grades.
- Order Confirmation: Pro-forma invoice issued; payment terms available for qualified accounts.
- Shipment & Tracking: DHL / FedEx / freight forwarder dispatch with full export documentation (CO, packing list, commercial invoice).
- After-Sales Support: Technical integration queries answered by our automation engineering team post-delivery.
Application-Specific FAQ
Q: Can this rack be used as a replacement in an existing 3500 system without replacing all modules?
A: Yes. The 3500/05 rack is backward-compatible with all current 3500 series I/O and power modules. Existing modules can be transferred directly into the replacement rack.
Q: Is the -01-01-00-00-01 suffix significant for ordering?
A: Yes. The suffix encodes configuration options including power supply type, communication options, and approval class. The -01-01-00-00-01 variant specifies standard AC power input with default communication and approval configuration. Always quote the full part number when ordering.
Q: Does this rack support TMR (Triple Modular Redundancy) configurations?
A: TMR is achieved at the module level using 3500/92 or 3500/93 voting modules installed within this rack. The rack itself is common to both standard and TMR system architectures.
Q: What is the lead time for this part?
A: In-stock units ship within 3–5 business days. For out-of-stock situations, typical lead time is 4–8 weeks depending on sourcing channel. Contact us for current availability.
Q: Can Konmask provide export documentation for cross-border shipments?
A: Yes. We provide full export documentation including commercial invoice, packing list, certificate of origin, and HS code classification (HS 9031.80 or as applicable) for all international orders.
