Schneider Electric BMXAMI0810 Analog Isolated High Level Input Module | Replacement, Equivalent & Selection Guide
The Schneider Electric BMXAMI0810 is an 8-channel analog isolated high-level input module designed for the Modicon M340 PLC platform. It delivers precise signal acquisition for industrial process control, offering galvanic isolation per channel to eliminate ground loops and ensure measurement integrity in demanding environments. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams sourcing the BMXAMI0810 or its functional equivalents.
Technical Specifications
- Part Number: BMXAMI0810
- Manufacturer: Schneider Electric
- Series: Modicon M340
- Module Type: Analog Isolated High Level Input
- Number of Channels: 8
- Input Signal Range: ±10 V / 0–10 V / 0–20 mA / 4–20 mA (configurable per channel)
- Resolution: 16-bit
- Isolation: Galvanic isolation per channel
- Conversion Time: ≤ 10 ms per channel
- Power Supply: 24 VDC (from backplane)
- Operating Temperature: 0 °C to +60 °C
- Protection Rating: IP20
- Certifications: CE, UL, cUL, IEC 61131-2
- Weight: ~500 g
- Mounting: Modicon M340 backplane rack
Compatible Replacement & Equivalent Models
When the BMXAMI0810 is unavailable or under evaluation, the following models may serve as functional replacements or equivalents depending on your system architecture and signal requirements:
- BMXAMI0410 – Schneider Electric Modicon M340, 4-channel analog isolated input (half-capacity drop-in for lower channel-count applications)
- BMXAMI0800 – 8-channel non-isolated analog input module; suitable where channel isolation is not required
- BMXAMM0600 – Mixed analog I/O module; consider when combined input/output is needed
- 140AII33000 – Schneider Quantum platform analog input; requires platform migration
- 1756-IF8 (Allen-Bradley ControlLogix) – Cross-brand 8-channel analog input; requires full platform migration and engineering re-mapping
- 6ES7331-7KF02-0AB0 (Siemens S7-300 SM331) – Cross-brand 8-channel analog input; requires platform migration
Note: Cross-brand replacements require hardware re-engineering, software re-programming, and full system validation. Always consult your system integrator before substitution.
Why Choose the Original BMXAMI0810
- Per-channel galvanic isolation eliminates ground loops in multi-sensor installations
- 16-bit resolution ensures high-accuracy signal acquisition for process control
- Native Modicon M340 compatibility — plug-and-play with Unity Pro / EcoStruxure Control Expert
- Flexible signal configuration — voltage and current inputs configurable per channel without hardware jumpers
- Proven reliability in continuous process industries including oil & gas, water treatment, and power generation
- Full Schneider Electric lifecycle support with firmware updates and spare parts availability
Typical Applications
- Temperature monitoring via 4–20 mA transmitters (pressure, flow, level)
- Process variable acquisition in chemical and pharmaceutical plants
- Power plant auxiliary control systems
- Water and wastewater treatment automation
- Building management and HVAC control
- Machine tool and packaging line integration
System Compatibility
- PLC Platform: Schneider Electric Modicon M340 (BMX series)
- Backplane: BMXXBP••00 series racks (4, 6, 8, 12-slot)
- Programming Software: Unity Pro / EcoStruxure Control Expert (all versions)
- Communication: Modbus TCP, CANopen, Ethernet I/P via M340 CPU
- Power Supply Modules: BMXCPS2000 / BMXCPS3500 / BMXCPS4002
- Not compatible with: Modicon Premium (TSX), Modicon Quantum (140), or M580 (BMENOC) platforms without adaptation
Selection Guide
Use the following criteria to confirm the BMXAMI0810 is the right module for your application:
- Channel count: Do you need 8 analog inputs? If 4 channels suffice, consider BMXAMI0410 for cost savings.
- Isolation requirement: If sensors share a common ground, use the isolated BMXAMI0810. If not, BMXAMI0800 (non-isolated) may be acceptable.
- Signal type: Confirm your transmitters output voltage (±10 V / 0–10 V) or current (0–20 mA / 4–20 mA) — the BMXAMI0810 supports both.
- Resolution: For high-precision process control (e.g., analytical instruments), 16-bit resolution is recommended — the BMXAMI0810 qualifies.
- Platform: Verify your rack is M340 BMX series. M580 or Premium racks are not compatible.
Quality Assurance & Sourcing
At Konmask.com, all Schneider Electric modules including the BMXAMI0810 are sourced through verified supply channels. Each unit undergoes:
- Visual and label authenticity inspection
- Functional power-on verification where applicable
- Secure anti-static packaging for transit protection
- Traceability documentation available upon request
We supply both new original and tested surplus units. Condition is clearly stated on each listing. Contact us for certificates of conformity or test reports.
How to Order
- Part Number: BMXAMI0810
- Manufacturer: Schneider Electric
- Lead Time: In-stock units ship within 1–3 business days; contact us for bulk or urgent orders
- MOQ: 1 unit
- Payment: T/T, PayPal, credit card accepted
- Shipping: DHL / FedEx / UPS worldwide; sea freight available for bulk
- Add to cart directly, or contact support@konmask.com for a formal quotation
Replacement & Compatibility FAQ
Q: Can BMXAMI0800 replace BMXAMI0810?
A: Functionally similar in channel count and signal range, but the BMXAMI0800 lacks per-channel galvanic isolation. Only substitute if your installation does not require channel isolation.
Q: Is BMXAMI0810 compatible with M580 racks?
A: No. The BMXAMI0810 is designed exclusively for M340 BMX backplanes. M580 uses the BME series modules.
Q: Can I use BMXAMI0810 with Unity Pro XL?
A: Yes. The module is fully supported in all versions of Unity Pro and EcoStruxure Control Expert.
Q: What is the difference between BMXAMI0810 and BMXAMI0410?
A: The BMXAMI0410 offers 4 isolated analog input channels versus 8 on the BMXAMI0810. Both share the same isolation architecture and signal range options.
Q: Do you supply new or refurbished units?
A: Both. Listing condition is clearly stated. New original units come in original Schneider Electric packaging. Surplus units are tested and cleaned.
